C-7
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
C.2.3.3 E3-12 Card Default Settings
Table C-3 lists the E3-12 card default settings.
E1_42.pmthresholds.vc4.farend.1day.SES 7 (seconds) 0 - 86400
E1_42.pmthresholds.vc4.farend.1day.UAS 10 (seconds) 0 - 86400
E1_42.pmthresholds.vc4.nearend.15min.BBE 25 (count) 0 - 2159100
E1_42.pmthresholds.vc4.nearend.15min.EB 15 (count) 0 - 7200000
E1_42.pmthresholds.vc4.nearend.15min.ES 12 (seconds) 0 - 900
E1_42.pmthresholds.vc4.nearend.15min.SES 3 (seconds) 0 - 900
E1_42.pmthresholds.vc4.nearend.15min.UAS 10 (seconds) 0 - 900
E1_42.pmthresholds.vc4.nearend.1day.BBE 250 (count) 0 - 207273600
E1_42.pmthresholds.vc4.nearend.1day.EB 125 (count) 0 - 691200000
E1_42.pmthresholds.vc4.nearend.1day.ES 100 (seconds) 0 - 86400
E1_42.pmthresholds.vc4.nearend.1day.SES 7 (seconds) 0 - 86400
E1_42.pmthresholds.vc4.nearend.1day.UAS 10 (seconds) 0 - 86400
E1_42.pmthresholds.vclo.farend.15min.BBE 15 (count) 0 - 539100
E1_42.pmthresholds.vclo.farend.15min.EB 18 (count) 0 - 1800000
E1_42.pmthresholds.vclo.farend.15min.ES 65 (seconds) 0 - 900
E1_42.pmthresholds.vclo.farend.15min.SES 10 (seconds) 0 - 900
E1_42.pmthresholds.vclo.farend.15min.UAS 10 (seconds) 0 - 900
E1_42.pmthresholds.vclo.farend.1day.BBE 150 (count) 0 - 51753600
E1_42.pmthresholds.vclo.farend.1day.EB 180 (count) 0 - 172800000
E1_42.pmthresholds.vclo.farend.1day.ES 648 (seconds) 0 - 86400
E1_42.pmthresholds.vclo.farend.1day.SES 100 (seconds) 0 - 86400
E1_42.pmthresholds.vclo.farend.1day.UAS 10 (seconds) 0 - 86400
E1_42.pmthresholds.vclo.nearend.15min.BBE 15 (count) 0 - 539100
E1_42.pmthresholds.vclo.nearend.15min.EB 18 (count) 0 - 1800000
E1_42.pmthresholds.vclo.nearend.15min.ES 65 (seconds) 0 - 900
E1_42.pmthresholds.vclo.nearend.15min.SES 10 (seconds) 0 - 900
E1_42.pmthresholds.vclo.nearend.15min.UAS 10 (seconds) 0 - 900
E1_42.pmthresholds.vclo.nearend.1day.BBE 150 (count) 0 - 51753600
E1_42.pmthresholds.vclo.nearend.1day.EB 180 (count) 0 - 172800000
E1_42.pmthresholds.vclo.nearend.1day.ES 648 (seconds) 0 - 86400
E1_42.pmthresholds.vclo.nearend.1day.SES 100 (seconds) 0 - 86400
E1_42.pmthresholds.vclo.nearend.1day.UAS 10 (seconds) 0 - 86400
Table C-2 E1-42 Card Default Settings (continued)
Default Name Default Value Default Domain
