C-6
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
C.2.3.2 E1-42 Card Default Settings
Table C-2 lists the E1-42 card default settings.
Table C-2 E1-42 Card Default Settings
Default Name Default Value Default Domain
E1_42.config.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
E1_42.config.LineCoding HDB3 HDB3
E1_42.config.LineType E1_MF E1_MF, E1_CRCMF, E1_UNFRAMED
E1_42.config.SDBER 1.00E-07 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
E1_42.config.SFBER 1.00E-04 1E-3, 1E-4, 1E-5
E1_42.config.State unlocked,
automaticInServic
e
unlocked, locked, disabled, locked, maintenance,
unlocked, automaticInService
E1_42.pmthresholds.line.nearend.15min.CV 9 (BPV count) 0 - 1388700
E1_42.pmthresholds.line.nearend.15min.ES 65 (seconds) 0 - 900
E1_42.pmthresholds.line.nearend.15min.LOSS 10 (seconds) 0 - 900
E1_42.pmthresholds.line.nearend.15min.SES 10 (seconds) 0 - 900
E1_42.pmthresholds.line.nearend.1day.CV 90 (BPV count) 0 - 133315200
E1_42.pmthresholds.line.nearend.1day.ES 648 (seconds) 0 - 86400
E1_42.pmthresholds.line.nearend.1day.LOSS 10 (seconds) 0 - 900
E1_42.pmthresholds.line.nearend.1day.SES 100 (seconds) 0 - 86400
E1_42.pmthresholds.path.nearend.15min.BBE 9 (count) 0 - 287100
E1_42.pmthresholds.path.nearend.15min.EB 9 (count) 0 - 450000
E1_42.pmthresholds.path.nearend.15min.ES 65 (seconds) 0 - 900
E1_42.pmthresholds.path.nearend.15min.SES 10 (seconds) 0 - 900
E1_42.pmthresholds.path.nearend.15min.UAS 10 (seconds) 0 - 900
E1_42.pmthresholds.path.nearend.1day.BBE 90 (count) 0 - 27561600
E1_42.pmthresholds.path.nearend.1day.EB 90 (count) 0 - 43200000
E1_42.pmthresholds.path.nearend.1day.ES 648 (seconds) 0 - 86400
E1_42.pmthresholds.path.nearend.1day.SES 100 (seconds) 0 - 86400
E1_42.pmthresholds.path.nearend.1day.UAS 10 (seconds) 0 - 86400
E1_42.pmthresholds.vc4.farend.15min.BBE 25 (count) 0 - 2159100
E1_42.pmthresholds.vc4.farend.15min.EB 15 (count) 0 - 7200000
E1_42.pmthresholds.vc4.farend.15min.ES 12 (seconds) 0 - 900
E1_42.pmthresholds.vc4.farend.15min.SES 3 (seconds) 0 - 900
E1_42.pmthresholds.vc4.farend.15min.UAS 10 (seconds) 0 - 900
E1_42.pmthresholds.vc4.farend.1day.BBE 250 (count) 0 - 207273600
E1_42.pmthresholds.vc4.farend.1day.EB 125 (count) 0 - 691200000
E1_42.pmthresholds.vc4.farend.1day.ES 100 (seconds) 0 - 86400
