C-5
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
E1.pmthresholds.path.nearend.15min.EB 9 (count) 0 - 450000
E1.pmthresholds.path.nearend.15min.ES 65 (seconds) 0 - 900
E1.pmthresholds.path.nearend.15min.SES 10 (seconds) 0 - 900
E1.pmthresholds.path.nearend.15min.UAS 10 (seconds) 0 - 900
E1.pmthresholds.path.nearend.1day.AISS 10 (seconds) 0 - 86400
E1.pmthresholds.path.nearend.1day.BBE 90 (count) 0 - 27561600
E1.pmthresholds.path.nearend.1day.EB 90 (count) 0 - 43200000
E1.pmthresholds.path.nearend.1day.ES 648 (seconds) 0 - 86400
E1.pmthresholds.path.nearend.1day.SES 100 (seconds) 0 - 86400
E1.pmthresholds.path.nearend.1day.UAS 10 (seconds) 0 - 86400
E1.pmthresholds.vclo.farend.15min.BBE 15 (count) 0 - 539100
E1.pmthresholds.vclo.farend.15min.EB 18 (count) 0 - 1800000
E1.pmthresholds.vclo.farend.15min.ES 65 (seconds) 0 - 900
E1.pmthresholds.vclo.farend.15min.SES 10 (seconds) 0 - 900
E1.pmthresholds.vclo.farend.15min.UAS 10 (seconds) 0 - 900
E1.pmthresholds.vclo.farend.1day.BBE 150 (count) 0 - 51753600
E1.pmthresholds.vclo.farend.1day.EB 180 (count) 0 - 172800000
E1.pmthresholds.vclo.farend.1day.ES 648 (seconds) 0 - 86400
E1.pmthresholds.vclo.farend.1day.SES 100 (seconds) 0 - 86400
E1.pmthresholds.vclo.farend.1day.UAS 10 (seconds) 0 - 86400
E1.pmthresholds.vclo.nearend.15min.BBE 15 (count) 0 - 539100
E1.pmthresholds.vclo.nearend.15min.EB 18 (count) 0 - 1800000
E1.pmthresholds.vclo.nearend.15min.ES 65 (seconds) 0 - 900
E1.pmthresholds.vclo.nearend.15min.SES 10 (seconds) 0 - 900
E1.pmthresholds.vclo.nearend.15min.UAS 10 (seconds) 0 - 900
E1.pmthresholds.vclo.nearend.1day.BBE 150 (count) 0 - 51753600
E1.pmthresholds.vclo.nearend.1day.EB 180 (count) 0 - 172800000
E1.pmthresholds.vclo.nearend.1day.ES 648 (seconds) 0 - 86400
E1.pmthresholds.vclo.nearend.1day.SES 100 (seconds) 0 - 86400
E1.pmthresholds.vclo.nearend.1day.UAS 10 (seconds) 0 - 86400
Table C-1 E1-N-14 Card Default Settings (continued)
Default Name Default Value Default Domain
