C-4
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix C Network Element Defaults
C.2.3 Defaults by Card
C.2.3 Defaults by Card
In the tables that follow, card defaults are defined by the default name, its factory-configured value, and
the domain of allowable values that you can assign to it.
Note Some default values, such as certain thresholds, are interdependent. Before changing a value, review the
domain for that default and any other related defaults for potential dependencies.
C.2.3.1 E1-N-14 Card Default Settings
Table C-1 lists the E1-N-14 card default settings.
Table C-1 E1-N-14 Card Default Settings
Default Name Default Value Default Domain
E1.config.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
E1.config.LineType E1_MF E1_MF, E1_CRCMF, E1_UNFRAMED
E1.config.SDBER 1.00E-07 1E-5, 1E-6, 1E-7, 1E-8, 1E-9
E1.config.SFBER 1.00E-04 1E-3, 1E-4, 1E-5
E1.config.State unlocked,
automaticInService
unlocked, locked, disabled, locked, maintenance,
unlocked, automaticInService
E1.pmthresholds.line.nearend.15min.CV 9 (BPV count) 0 - 1388700
E1.pmthresholds.line.nearend.15min.ES 65 (seconds) 0 - 900
E1.pmthresholds.line.nearend.15min.LOSS 10 (seconds) 0 - 900
E1.pmthresholds.line.nearend.15min.SES 10 (seconds) 0 - 900
E1.pmthresholds.line.nearend.1day.CV 90 (BPV count) 0 - 133315200
E1.pmthresholds.line.nearend.1day.ES 648 (seconds) 0 - 86400
E1.pmthresholds.line.nearend.1day.LOSS 10 (seconds) 0 - 900
E1.pmthresholds.line.nearend.1day.SES 100 (seconds) 0 - 86400
E1.pmthresholds.path.farend.15min.BBE 0 (count) 0 - 287100
E1.pmthresholds.path.farend.15min.EB 0 (count) 0 - 450000
E1.pmthresholds.path.farend.15min.ES 0 (seconds) 0 - 900
E1.pmthresholds.path.farend.15min.SES 0 (seconds) 0 - 900
E1.pmthresholds.path.farend.15min.UAS 0 (seconds) 0 - 900
E1.pmthresholds.path.farend.1day.BBE 0 (count) 0 - 27561600
E1.pmthresholds.path.farend.1day.EB 0 (count) 0 - 450000
E1.pmthresholds.path.farend.1day.ES 0 (seconds) 0 - 86400
E1.pmthresholds.path.farend.1day.SES 0 (seconds) 0 - 86400
E1.pmthresholds.path.farend.1day.UAS 0 (seconds) 0 - 86400
E1.pmthresholds.path.nearend.15min.AISS 10 (seconds) 0 - 900
E1.pmthresholds.path.nearend.15min.BBE 9 (count) 0 - 287100
