Appendix C Network Element Defaults
C.2 Card Default Settings
Note Changing some node-level provisioning via NE defaults can cause CTC disconnection or a
reboot of the node in order for the provisioning to take effect. Before you change a default, check
in the Side Effects column of the Defaults editor (right-click a column header and select Show
Column > Side Effects) and be prepared for the occurrence of any side effects listed for that
default.
C.2 Card Default Settings
The tables in this section list the default settings for each SDH card. Cisco provides several types of
user-configurable defaults for Cisco ONS 15454 SDH optical, electrical, storage access networking, and
Ethernet (or data) cards. Types of card defaults can be broadly grouped by function, as outlined in the
following subsections. For information about individual card settings, refer to the “Change Card
Settings” chapter of the Cisco ONS 15454 SDH Procedure Guide.
Note When the card level defaults are changed, the new provisioning done after the defaults have changed is
affected. Existing provisioning remains unaffected.
Note To view DWDM card defaults consult the Cisco ONS 15454 DWDM Reference Manual.
The following types of defaults are defined for SONET cards.
C.2.1 Configuration Defaults
Most card and port-level configuration defaults correspond to settings found in the CTC card-level
Provisioning tabs.
Note The full set of Automatic Laser Shutdown (ALS) configuration defaults can be found in the CTC
card-level Maintenance > ALS tab for supported cards. ALS defaults are supported for STM1-8, STM16,
STM64, STM64-XFP, and MRC-12 cards.
Configuration defaults that correspond to settings that are reachable from the CTC card-level
Provisioning tabs (except as noted) include the following types of options (arranged by CTC subtab):
• Line—(E1-N-14, E1-42, E3-12, DS3i-N-12, STM-N, MRC-12, G-series, and CE-series cards)
Line-level configuration settings.
Note MRC-12 line configuration defaults are defined on a per STM-N rate basis.
• VC4—(STM-N cards) VC4-level configuration settings.
• Port—(FC_MR-4 cards only) Port line-level configuration, distance extension, and enhanced
FC/FICON ISL settings.
• Card—(ML-series, and FC_MR-4 cards) FC_MR-4 card mode settings (FC_MR-4 only); or framing
mode (ML-series cards).
