B-5
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix B Administrative and Service States
B.3.1 Card Service State Transitions
Locked-disabled,mismatchOfEquipment &
maintenance
Change the administrative state
to Unlocked.
Unlocked-disabled,mismatchOfEquipment
Pull the card. Locked-disabled,maintenance &
notInstalled
Delete the card. Locked-disabled,unassigned if the card is
valid
Locked-disabled,mismatchOfEquipment &
unassigned if the card is invalid
Locked-disabled,mismatchOfEquipment &
unassigned
Pull the card. Locked-disabled,unassigned & notInstalled
Provision the card. Unlocked-disabled,mismatchOfEquipment
Locked-disabled,maintenance &
softwareDownload
Restart completed. Locked-enabled,maintenance
Pull the card. Locked-disabled,maintenance &
notInstalled
Locked-disabled,maintenance &
notInstalled
Change the administrative state
to Unlocked.
Unlocked-disabled,notInstalled
Insert a valid card. Locked-disabled,maintenance &
softwareDownload
Insert an invalid card. Locked-disabled,mismatchOfEquipment &
maintenance
Delete the card. Locked-disabled,unassigned & notInstalled
Locked-disabled,unassigned Pull the card. Locked-disabled,unassigned & notInstalled
Provision an invalid card. Unlocked-disabled,mismatchOfEquipment
Provision a valid card. Unlocked-disabled,softwareDownload
Locked-disabled,unassigned & notInstalled Insert a valid card. Unlocked-disabled,softwareDownload
Insert an invalid card. Locked-disabled,mismatchOfEquipment &
unassigned
Preprovision a card. Unlocked-disabled,automaticInService &
notInstalled
Locked-disabled,failed & maintenance Pull the card. Locked-disabled,maintenance &
notInstalled
Delete the card. Locked-disabled,unassigned
Change the administrative state
to Unlocked.
Unlocked-disabled,failed
Reset the card. Locked-disabled,maintenance &
softwareDownload
Alarm/condition is cleared. Unlocked-enabled
Table B-4 ONS 15454 SDH Card Service State Transitions (continued)
Current Service State Action Next Service State
