B-3
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix B Administrative and Service States
B.3 Service State Transitions
Note When an entity is put in the Locked,maintenance administrative state, the ONS 15454 SDH suppresses
all standing alarms on that entity. All alarms and events appear on the Conditions tab. You can change
this behavior for the LPBKFACILITY and LPBKTERMINAL alarms. To display these alarms on the
Alarms tab, set the NODE.general.ReportLoopbackConditionsOnUnlocked,MaintenancePorts to TRUE
on the NE Defaults tab.
Note A change in the administrative state of an entity does not change the service state of supporting or
supported entities.
B.3 Service State Transitions
This section describes the transition from one service state to the next for cards, ports, and
cross-connects. A service state transition is based on the action performed on the entity.
B.3.1 Card Service State Transitions
Table B-4 lists card service state transitions.
Table B-3 ONS 15454 SDH Administrative States
Administrative State (PST,SST) Definition
Unlocked Puts the entity in service.
Unlocked,automaticInservice Puts the entity in automatic in-service.
Locked,disabled Removes the entity from service and disables it.
Locked,maintenance Removes the entity from service for maintenance.
Locked,outOfGroup (VCAT circuits only) Removes a VCAT member cross-connect
from service and from the group of members.
Table B-4 ONS 15454 SDH Card Service State Transitions
Current Service State Action Next Service State
Unlocked-enabled Change the administrative state
to Locked,maintenance.
Locked-enabled,maintenance
Delete the card. Locked-disabled,unassigned
Pull the card. Unlocked-disabled,notInstalled
Reset the card. Unlocked-disabled,softwareDownload
Alarm/condition is raised. Unlocked-disabled,failed
