1-5
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Chapter 1 Shelf and FMEC Hardware
1.2 Front Door
Figure 1-3 Removing the ONS 15454 SDH Front Door
An erasable label is pasted on the inside of the front door (Figure 1-4). You can use the label to record
slot assignments, port assignments, card types, node ID, rack ID, and serial number for the
ONS 15454 SDH.
61237
FAN FAIL
CRIT
MAJ
MIN
Door hinge
Assembly hinge pin
Assembly hinge
Translucent
circles
for LED
viewing
