Appendix A Hardware Specifications
A.7.7 ML1000-2 Card Specifications
– Depth: 228.6 mm (9.000 in.)
– Depth with backplane connector: 235 mm (9.250 in.)
– Weight (not including clam shell): 2.3 lb (1.0 kg)
• Compliance. ONS 15454 SDH cards, when installed in a system, comply with these standards:
– Safety: IEC 60950, EN 60950, UL 60950, CSA C22.2 No. 60950, TS 001, and AS/NZS 3260
A.7.7 ML1000-2 Card Specifications
The ML1000-2 card has the following specifications:
• Environmental
– Operating temperature: –5 to +55 degrees Celsius (+23 to +131 degrees Fahrenheit)
– Operating humidity: 5 to 95 percent, noncondensing
– Power consumption: 49.00 W, 1.02 A at –48 V, 167.3 BTU/hr
• Dimensions
– Height: 321.3 mm (12.650 in.)
– Width: 18.2 mm (0.716 in.)
– Depth: 228.6 mm (9.000 in.)
– Depth with backplane connector: 235 mm (9.250 in.)
– Weight (not including clam shell): 2.1 lb (0.9 kg)
• Compliance: ONS 15454 SDH optical cards, when installed in a system, comply with these
standards:
– Safety: IEC 60950, EN 60950, UL 60950, CSA C22.2 No. 60950, TS 001, AS/NZS 3260,
IEC 60825-1, IEC 60825-2, 21 CFR 1040-10, and 21 CFR 1040.11
– Class 1 laser product
A.7.8 ML100X-8 Card Specifications
The ML100X-8 card has the following specifications:
• Environmental
– Operating temperature: –5 to +55 degrees Celsius (+23 to +131 degrees Fahrenheit)
– Operating humidity: 5 to 95 percent, noncondensing
– Power consumption: 65.00 W, 1.35 A at –48 V, 221.93 BTU/hr
• Dimensions
– Height: 321.3 mm (12.650 in.)
– Width: 18.2 mm (0.716 in.)
– Depth: 228.6 mm (9.000 in.)
– Depth with backplane connector: 235 mm (9.250 in.)
– Weight (not including clam shell): 2.1 lb (0.9 kg)
