Appendix A Hardware Specifications
A.6.16 OC192/STM64 Any Reach Card Specifications
• Line
– Bit rate: STM-64 (9.9520 Gbps)
– Fiber: 1310-nm single-mode
– Connectors: LC duplex connector for the XFP
– Compliance: ITU G.957 and GR-253
• Transmitter
– Maximum transmitter output power: –1 dBm
– Minimum transmitter output power: –6 dBm
• Receiver
– Maximum receiver level: –1 dBm
– Minimum receiver level: –11 dBm
– Receiver input wavelength range: 1260 to 1565 nm
• Environmental
– Operating temperature: 0 to +55 degrees Celsius (32 to +131 degrees Fahrenheit)
– Operating humidity: 5 to 95 percent, noncondensing
– Power consumption: 40.00 W, 0.83 A at –48 V, 136.49 BTU/hr
• Dimensions
– Height: 12.650 in. (321.3 mm)
– Width: 0.716 in. (18.2 mm)
– Depth: 9.000 in. (228.6 mm)
– Depth with backplane connector: 9.250 in. (235 mm)
– Weight (not including clam shell): 3.1 lb (1.3 kg)
A.6.16 OC192/STM64 Any Reach Card Specifications
The OC192/STM64 Any Reach card has the following specifications:
Note The OC192/STM64 Any Reach card is designated as OC192-XFP in CTC.
• Line
– Bit rate: STM-64 (9.9520 Gbps)
– Fiber: 1310-nm single-mode for ONS-XC-10G-S1 XFP, 1550-nm single mode for
ONS-XC-10G-I2 and ONS-XC-10G-L2 XFPs
– Connectors: LC duplex connector for the XFPs
– Compliance: ITU G.957 and GR-253
• Transmitter
– Maximum transmitter output power: Depends on SFP (see the “A.2 SFP and XFP
Specifications” section on page A-3)
