Appendix A Hardware Specifications
A.6.15 OC192SR1/STM64IO Short Reach Card Specifications
– Fiber: 1550-nm single-mode
– Connectors: LC duplex connector for each SFP
– Compliance: ITU-T G.957 and Telcordia GR-253
• Transmitter
– Maximum transmitter output power: Depends on SFP (see A.2 SFP and XFP Specifications,
page A-3)
– Minimum transmitter output power: Depends on SFP (see A.2 SFP and XFP Specifications,
page A-3)
– Center wavelength: See wavelength plan
– Center wavelength accuracy: 1 nm to 4 nm, depending on SFP
– Transmitter: Fabry Perot and DFB laser
• Receiver
– Maximum receiver level: Depends on SFP (see A.2 SFP and XFP Specifications, page A-3)
– Minimum receiver level: Depends on SFP (see A.2 SFP and XFP Specifications, page A-3)
– Receiver: PIN PD
– Receiver input wavelength range: Depends on SFP
• Environmental
– Operating temperature: –40 to +55 degrees Celsius (–40 to +149 degrees Fahrenheit)
– Operating humidity: 5 to 95 percent, noncondensing
– Power consumption: 38.00 W, 0.79 A at –48 V, 129.66 BTU/hr
• Dimensions
– Height: 12.650 in. (321.3 mm)
– Width: 0.716 in. (18.2 mm)
– Depth: 9.000 in. (228.6 mm)
– Depth with backplane connector: 9.250 in. (235 mm)
– Weight (not including clam shell): 3.1 lb (1.3 kg)
• Wavelength Plan: Currently available wavelengths and versions of the 15454_MRC-12 card:
– For ONS-SC-2G-30.3 through ONS-SC-2G-60.0 SFPs: 1530.33 nm to 1560.61 nm
(32 distinct wavelengths at 100 GHz spacing)
– For ONS-SE-622-1470 through ONS-SE-622-1610 SFPs: 1470 to 1610 nm
(eight distinct wavelengths at 2500 GHz spacing)
– For ONS_SE-155-1470 through ONS-SE-155-1610 SFPs: 1470 to 1610 nm
(eight distinct wavelengths at 2500 GHz spacing)
A.6.15 OC192SR1/STM64IO Short Reach Card Specifications
The OC192SR1/STM64IO Short Reach card has the following specifications:
Note The OC192SR1/STM64IP Short Reach card is designated as OC192-XFP in CTC.
