A-9
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix A Hardware Specifications
A.4 Common Control Card Specifications
A.4 Common Control Card Specifications
This section provides specifications for the common control cards.
For compliance information, refer to the Cisco Optical Transport Products Safety and Compliance
Information document.
Optical
OC3 IR 4/STM1 SH 1310 15454E-S1.1-4 —
OC3 IR/STM1 SH 1310-8 15454E-S1.1-8 —
OC12 IR/STM4 SH 1310 15454E-S4.1-1 —
OC12 LR/STM4 LH 1310 15454E-L4.1-1 —
OC12 LR/STM4 LH 1550 15454E-L4.2-1 —
OC12 LR/STM4 SH 1310-4 15454E-L4.1-4 —
OC48 IR/STM16 SH AS 1310 15454E-S16.1-1 —
OC48 LR/STM16 LH AS 1550 15454E-S16.2-1 —
OC48 ELR/STM16 EH 100 GHz 15454E-EL16HXXXX —
OC192 SR/STM64 IO 1310 15454E-I65.1 —
OC192 IR/STM64 SH 1550 15454E-S64.2 —
OC192 LR/STM64 LH 1550 15454E-L64.2.1 —
OC192 LR/STM64 LH ITU
15xx.xx
15454E-64-LXX.X —
15454_MRC-12 — 15454-MRC-12-T
OC192SR1/STM64IO Short
Reach and OC192/STM64 Any
Reach
1
15454_OC192SR1/
STM64IO Short Reach
and 15454_OC192/
STM64 Any Reach
—
Ethernet
E100T-G 15454-E100T-G —
E1000-2-G 15454-E1000-2-G —
G1K-4 15454-G1K-4 —
ML100T-12 15454-ML100T-12 —
ML1000-2 15454-ML1000-2 —
ML100X-8 — 15454-ML100X-8
CE-100T-8 15454-CE100T-8 —
CE-1000-4 15454-CE1000-4 —
Storage Access
Networking
FC_MR-4 15454-FC_MR-4 —
1. These cards are referred to as OC192-XFP in CTC.
Table A-3 Card Temperature Ranges and Product Names (continued)
Card Type Card Name
C-Temp Product Name
(0 to +55 degrees
Celsius, 32 to 131
degrees Fahrenheit)
I-Temp Product Name
(–40 to +65 degrees
Celsius, –40 to 149
degrees Fahrenheit)
