Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix A Hardware Specifications
A.3.2 Temperature Ranges
A.3.2 Temperature Ranges
Table A-3 provides temperature ranges and product names for ONS 15454 SDH cards.
Note The I-Temp symbol is displayed on the faceplate of an I-Temp compliant card. A card without this
symbol is C-Temp compliant.
Optical Cards
OC3 IR 4/STM1 SH 1310 19.20 0.40 65.6
OC3IR/STM1SH 1310-8 23.00 0.48 78.5
OC12 IR/STM4 SH 1310 9.28 0.19 31.7
OC12 LR/STM4 LH 1310 9.28 0.19 31.7
OC12 LR/STM4 LH 1550 9.28 0.19 31.7
OC12 LR/STM4 SH 1310-4 35.60 0.74 121.6
OC48 IR/STM16 SH AS 1310 37.20 0.78 127.0
OC48 LR/STM16 LH AS 1550 37.20 0.78 127.0
OC48 ELR/STM16 EH 100 GHz 31.20 0.65 106.5
OC192 SR/STM64 IO 1310 42.00 0.88 143.4
OC192 IR/STM64 SH 1550 44.00 0.92 150.2
OC192 LR/STM64 LH 1550 72.20 1.50 246.5
OC192 LR/STM64 LH ITU 15xx.xx 46.00 0.96 157.1
15454_MRC-12 38 0.79 129.66
OC192SR1/STM64IO Short Reach
and OC192/STM64 Any Reach
1
40 0.83 136.49
Ethernet Cards
E100T-G 60.96 1.27 208.00
E1000-2-G 38.88 (inlcuding
GBICs)
0.81 182.67
G1K-4 55.20 (including
GBICs)
1.15 215.11
ML100T-12 53.00 1.10 181.0
ML1000-2 44.1(including SFPs) 0.92 167.3
ML100X-8 65 1.35 221.93
CE-100T-8 53.14 1.10 181.3
CE-1000-4 60 1.25 204.80
Storage Access
Networking
FC_MR-4 (Fibre Channel) 60 1.25 204.80
1. These cards are referred to as OC192-XFP in CTC.
Table A-2 Individual Card Power Requirements (continued)
Card Type Card Name Watts Amperes BTU/Hr
