Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Appendix A Hardware Specifications
A.3 General Card Specifications
A.3 General Card Specifications
This section provides power consumption and temperature ranges for all ONS 15454 SDH cards.
A.3.1 Power Consumption
Table A-2 provides power consumption information for the ONS 15454 SDH cards.
ONS-SC-2G-30.3
through
ONS-SC-2G-60.6
OC-48 DWDM 0 to 4 –28 to –9
ONS-SI-622-I1 OC-3/OC-12 IR1 Dual
rate
–15 to –8 –28 to –8
ONS-SI-622-L1 OC-21 LR1 –3 to 2 –28 to –8
ONS-SI-622-L2 OC-12 LR2 –3 to 2 –28 to –8
ONS-SE-622-1470
through
ONS-SE-622-1610
OC-12 CWDM 0 to 5 –28 to –7
ONS-SI-155-I1 OC-3 IR1 –15 to –8 –28 to –8
ONS-SI-155-L1 OC-3 LR1 –5 to 0 –34 to –10
ONS-SI-155-L2 OC-3 LR2 –5 to 0 –34 to –10
ONS_SE-155-1470
through
ONS-SE-155-1610
OC-3 CWDM 0 to 5 –34 to –7
ONS-XC-10G-S1 OC-192 SR1 –6 to –1 –11 to –1
ONS-XC-10G-I2 OC-192 IR2 –1 to +2 –14 to +2
ONS-XC-10G-L2 OC-192 LR2 0 to 4 –24 to –7
ONS-SE-100-FX Fast Ethernet –20 to –14 –30 to –14
ONS-SE-100-LX10 Fast Ethernet –15 to –8 –25 to –8
1. Based on any valid 8B/10B code pattern measured at, or extrapolated to, 10E-15 BER measured at center of eye
2. Minimum Stressed Sensitivity (10-12): -12.5(62.5um) and -13.5(50um) dBm
3. Minimum Stressed Sensitivity (10
–12
): -14.4 dBm
Table A-1 SFP and XFP Specifications (continued)
SFP/XFP Product ID Interface
Transmitter Output
Power Min/Max (dBm)
Receiver Input Power
Min/Max (dBm)
