16-8
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Chapter 16 SNMP
16.7 SNMP Trap Content
The cerentGenericPmStatsCurrentTable validates the current PM value using the
cerentGenericPmStatsCurrentValid object and registers the number of valid intervals with historical PM
statistics in the cerentGenericPmStatsCurrentValidIntervals object.
PM values are provided in 64-bit and 32-bit formats. The 64-bit values in
cerentGenericPmStatsCurrentHCValue can be used with agents that support SNMPv2. The two 32-bit
values (cerentGenericPmStatsCurrentValue and cerentGenericPmStatsCurrentOverFlowValue) can be
used by NMS that only support SNMPv1. The cerentGenericPmStatsCurrentTable is shown in
Table 16-5.
The third table in the MIB, cerentGenericPmStatsIntervalTable, obtains historic PM values for the
monitor types. This table is indexed based on the interface index, monitor type, location, time period,
and interval number. It validates the current PM value in the cerentGenericPmStatsIntervalValid object.
This table is indexed based on interface index (cerentGenericPmStatsIntervalIndex), monitor type
(cerentGenericPMStatsIntervalMonType), location (cerentGenericPmStatsIntervalLocation), and period
(cerentGenericPmStatsIntervalPeriod). The syntax of cerentGenericPmStatsIntervalIndex is type
cerentLocation, defined in CERENT-TC.mib. The syntax of cerentGenericPmStatsIntervalMonType is
type cerentMonitor, defined in CERENT-TC.mib. The syntax of cerentGernicPmStatsIntervalPeriod is
type cerentPeriod, defined in CERENT-TC.mib.
The table provides historic PM values in 64-bit and 32-bit formats. The 64-bit values contained in the
cerentGenericPmStatsIntervalHCValue table can be used with SNMPv2 agents. The two 32-bit values
(cerentGenericPmStatsIntervalValue and cerentGenericPmStatsIntervalOverFlowValue) can be used by
SNMPv1 NMS. The cerentGenericPmStatsIntervalTable is shown in Table 16-6.
16.7 SNMP Trap Content
The ONS 15454 SDH generates all alarms and events, such as raises and clears, as SNMP traps. These
contain the following information:
Table 16-5 cerentGenericPmStatsCurrentTable
Index Objects Informational Objects
cerentGenericPmStatsCurrentIndex cerentGenericPmStatsCurrentValue
cerentGenericPmStatsCurrentMonType cerentGenericPmStatsCurrentOverFlowValue
cerentGenericPmStatsCurrentLocation cerentGenericPmStatsCurrentHCValue
cerentGenericPmStatsCurrentPeriod cerentGenericPmStatsCurrentValidData
— cerentGenericPmStatsCurrentValidIntervals
Table 16-6 cerentGenericPmStatsIntervalTable
Index Objects Informational Objects
cerentGenericPmStatsIntervalIndex cerentGenericPmStatsIntervalValue
cerentGenericPmStatsIntervalMonType cerentGenericPmStatsIntervalOverFlowValue
cerentGenericPmStatsIntervalLocation cerentGenericPmStatsIntervalHCValue
cerentGenericPmStatsIntervalPeriod cerentGenericPmStatsIntervalValidData
cerentGenericPmStatsIntervalNumber —
