16-6
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Chapter 16 SNMP
16.6.2 Proprietary ONS 15454 SDH MIBS
16.6.2 Proprietary ONS 15454 SDH MIBS
Each ONS system is shipped with a software CD containing applicable proprietary MIBs. Table 16-3
lists the proprietary MIBs for the ONS 15454 SDH.
Note If you cannot compile the proprietary MIBs correctly, log into the Technical Support Website at
http://www.cisco.com/techsupport or call Cisco TAC (800) 553-2447.
Note When SNMP indicates that the wavelength is unknown, it means that the corresponding card
(MXP_2.5G_10E, TXP_MR_10E, MXP_2.5G_10G, TXP_MR_10G, TXP_MR_2.5G, or
TXPP_MR_2.5G) works with the first tunable wavelength.
2674 P-BRIDGE-MIB-rfc2674.mib
Q-BRIDGE-MIB-rfc2674.mib
Definitions of Managed Objects for Bridges with Traffic
Classes, Multicast Filtering and Virtual LAN Extensions
3273 HC-RMON-MIB The MIB module for managing remote monitoring device
implementations, augmenting the original RMON MIB
as specified in RFC 2819 and RFC 1513 and RMON-2
MIB as specified in RFC 2021
1. RFC = Request for Comment
The size of mediaIndependentOwner is limited to 32 characters.
Table 16-2 IETF Standard MIBs Implemented in the ONS 15454 SDH System (continued)
RFC
1
Number Module Name Title/Comments
Table 16-3 ONS 15454 SDH Proprietary MIBs
MIB
Number Module Name
1 CERENT-GLOBAL-REGISTRY.mib
2 CERENT-TC.mib
3 CERENT-454.mib
4 CERENT-GENERIC.mib (not applicable to
ONS 15454 SDH)
5CISCO-SMI.mib
6 CISCO-VOA-MIB.mib
7 CERENT-MSDWDM-MIB.mib
8 CERENT-OPTICAL-MONITOR-MIB.mib
9 CERENT-HC-RMON-MIB.mib
10 CERENT-ENVMON-MIB.mib
11 CERENT-GENERIC-PM-MIB.mib
