Chapter 15 Performance Monitoring
15.8 Performance Monitoring for the Fiber Channel Card
Figure 15-15 PM Read Points for the MRC-12 Card
Table 15-21 lists the PM parameters for MRC-12 cards.
15.8 Performance Monitoring for the Fiber Channel Card
The following sections define PM parameters and definitions for the FC_MR-4 card.
15.8.1 FC_MR-4 Card Performance Monitoring Parameters
CTC provides FC_MR-4 performance information, including line-level parameters, port bandwidth
consumption, and historical statistics. The FC_MR-4 card performance information is divided into the
Statistics, Utilization, and History tabbed windows within the card view Performance tab window.
134562
XC Card STM-N
iBPIA
ASIC
iBPIA
ASIC
Regenerator Section PM (SDH
Near-End RS-EB
Near-End RS-ES
Near-End RS-SES
Near-End RS-BBE
Near-End RS-OFS
Multiplex Section PM (SDH)
Near-End MS-EB
Near-End MS-ES
Near-End MS-SES
Near-End MS-UAS
Near-End MS-BBE
Near-End MS-FC
Far-End MS-EB
Far-End MS-ES
Far-End MS-SES
Far-End MS-UAS
Far-End MS-BBE
Far-End MS-FC
Section PM - SONET
Near-End CV-S
Near-End ES-S
Near-End SEFS-S
Line PMs (SONET)
Near-End CV-L
Near-End ES-L
Near-End SES-L
Near-End UAS-L
Near-End FC-L
Far-End CV-LFE
Far-End ES-LFE
Far-End SES-LFE
Far-End UAS-LFE
MRC-12/MRC-2.5G-12 Multirate Card
ONS 15454 SDH
PMs read on Amazon ASIC
Table 15-21 MRC-12 Card PMs
Regenerator Section (NE) Multiplex Section (NE) Multiplex Section (FE)
RS-EB
RS-ES
RS-SES
RS-BBE
RS-OFS
MS-EB
MS-ES
MS-SES
MS-UAS
MS-BBE
MS-FC
MS-EB
MS-ES
MS-SES
MS-UAS
MS-BBE
MS-FC
