Chapter 15 Performance Monitoring
15.6.4 CE-Series Ethernet Card Performance Monitoring Parameters
dot3StatsFrameTooLong Indicates the count of frames received on a particular interface
that exceed the maximum permitted frame size.
etherStatsUndersizePkts Indicates the total number of packets received that were less than
64 octets long (excluding framing bits, but including FCS octets)
and were otherwise well formed.
etherStatsUndersizePkts Indicates the total number of packets received that were less than
64 octets long (excluding framing bits, but including FCS octets)
and were otherwise well formed.
etherStatsFragments Indicates the total number of packets received that were less than
64 octets in length (excluding framing bits but including FCS
octets) and had either a bad FCS with an integral number of
octets (FCS error) or a bad FCS with a nonintegral number of
octets (alignment error).
Note It is entirely normal for etherStatsFragments to
increment. This is because it counts both runts (which
are normal occurrences due to collisions) and noise hits.
etherStatsPkts64Octets Indicates the total number of packets (including bad packets)
received that were 64 octets in length (excluding framing bits but
including FCS octets).
etherStatsPkts65to127Octets Indicates the total number of packets (including bad packets)
received that were between 65 and 127 octets in length inclusive
(excluding framing bits but including FCS octets).
etherStatsPkts128to255Octets Indicates the total number of packets (including bad packets)
received that were between 128 and 255 octets in length inclusive
(excluding framing bits but including FCS octets).
etherStatsPkts256to511Octets Indicates the total number of packets (including bad packets)
received that were between 256 and 511 octets in length inclusive
(excluding framing bits but including FCS octets).
etherStatsPkts512to1023Octets Indicates the total number of packets (including bad packets)
received that were between 512 and 1023 octets in length
inclusive (excluding framing bits but including FCS octets).
etherStatsPkts1024to1518
Octets
Indicates the total number of packets (including bad packets)
received that were between 1024 and 1518 octets in length
inclusive (excluding framing bits but including FCS octets).
etherStatsBroadcastPkts Indicates the total number of good packets received that were
directed to the broadcast address. Note that this does not include
multicast packets.
etherStatsMulticastPkts Indicates the total number of good packets received that were
directed to a multicast address. Note that this number does not
include packets directed to the broadcast address.
etherStatsOversizePkts Indicates the total number of packets received that were longer
than 1518 octets (excluding framing bits, but including FCS
octets) and were otherwise well formed. Note that for tagged
interfaces, this number becomes 1522 bytes.
Table 15-14 CE-Series Ether Ports PM Parameters (continued)
Parameter Meaning
