Note When an entity is put in the Locked,maintenance administrative state, the ONS 15454 SDH suppresses
all standing alarms on that entity. All alarms and events appear on the Conditions tab. You can change
this behavior for the LPBKFACILITY and LPBKTERMINAL alarms. To display these alarms on the
Alarms tab, set the NODE.general.ReportLoopbackConditionsOnPortsInLocked,Maintenance to TRUE
on the NE Defaults tab.
Table 14-2 lists the color codes for alarm and condition severities. The inherited (I) and unset (U)
severities are only listed in the network view Provisioning > Alarm Profiles tab.
Path Width Indicates how many VC-4s are contained in an alarmed path. (For any non-VC-4 object,
such as a VC-3, the column is blank.) This information complements the alarm object
notation, which is explained in Table 14-3.
Sev Severity level: CR (Critical), MJ (Major), MN (Minor), NA (Not Alarmed), NR
(Not Reported).
ST Status: R (raised), C (clear), T (transient).
SA When checked, indicates a service-affecting alarm.
Cond The error message/alarm name. These names are alphabetically defined in the “Alarm
Troubleshooting” chapter of the Cisco ONS 15454 SDH Troubleshooting Guide.
Description Description of the alarm.
Num Num (number) is the quantity of alarm messages received, and is incremented
automatically as alarms occur to display the current total of received error
messages.(The column is hidden by default; to view it, right-click a column and choose
Show Column > Num.)
Ref Ref (reference) is a unique identification number assigned to each alarm to reference a
specific alarm message that is displayed. (The column is hidden by default; to view it,
right-click a column and choose Show Column > Ref.)
Table 14-1 Alarms Column Descriptions (continued)
Column Information Recorded
Table 14-2 Color Codes for Alarm and Condition Severities
Color Description
Red Raised Critical (CR) alarm
Orange Raised Major (MJ) alarm
Yellow Raised Minor (MN) alarm
Magenta (pink) Raised Not Alarmed (NA) condition
Blue Raised Not Reported (NR) condition
White Cleared (C) alarm or condition
