Chapter 13 Management Network Connectivity
13.5 External Firewalls
13.5 External Firewalls
This section provides sample access control lists for external firewalls. Table 13-9 lists the ports that are
used by the TCC2/TCC2P card.
The following access control list (ACL) example shows a firewall configuration when the proxy server
gateway setting is not enabled. In the example, the CTC workstation's address is 192.168.10.10. and the
ONS 15454 SDH address is 10.10.10.100 The firewall is attached to the GNE CTC, so inbound is CTC
to the GNE and outbound is from the GNE to CTC. The CTC Common Object Request Broker
Architecture (CORBA) Standard constant is 683 and the TCC CORBA Default TCC Fixed (57790).
access-list 100 remark *** Inbound ACL, CTC -> NE ***
access-list 100 remark
Table 13-9 Ports Used by the TCC2/TCC2P
Port Function Action
1
1. D = deny, NA = not applicable, OK = do not deny
0Never used D
20 FTP D
21 FTP control D
22 SSH (Secure Shell) D
23 Telnet D
80 HTTP D
111 SUNRPC (Sun Remote Procedure Call) NA
161 SNMP traps destinations D
162 SNMP traps destinations D
513 rlogin D
683 CORBA IIOP OK
1080 Proxy server (socks) D
2001-2017 I/O card Telnet D
2018 DCC processor on active TCC2/TCC2P D
2361 TL1 D
3082 Raw TL1 D
3083 TL1 D
5001 BLSR server port D
5002 BLSR client port D
7200 SNMP alarm input port D
9100 EQM port D
9401 TCC boot port D
9999 Flash manager D
10240-12287 Proxy client D
57790 Default TCC listener port OK
