13-23
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Chapter 13 Management Network Connectivity
13.3 Provisionable Patchcords
Note If the OCSM card is installed in Slot 8, provisionable patchcords from OC-N ports to the following cards
are not supported on the same node: MXP_2.5G_10G, TXP_MR_10G, TXP(P)_MR_2.5G,
MXP_2.5G_10E, TXP_MR_10E, 32MUX-O, 32DMX-O, 32-WSS, or 32-DMX.
Table 13-6 lists the supported card combinations for client-to-client ports in a patchcord.
Table 13-7 lists the supported card combinations for trunk-to-trunk ports in a patchcord.
Table 13-5 Client-to-Trunk Card Combinations for Provisionable Patchcords
Trunk Cards
Client Cards
MXP_2.5G_10G/
TXP_MR_10G
TXP(P)_MR_
2.5G
MXP_2.5G_10E/
TXP_MR_10E
32MUX-O
32DMX-O
32-WSS/
32-DMX ADxC 4MD
MXP_2.5G_10G/
TXP_MR_10G
— — — Yes Yes Yes Yes
TXPP_MR_2.5G — — — Yes Yes Yes Yes
MXP_2.5G_10E/
TXP_MR_10E
— — — Yes Yes Yes Yes
MXPP_MR_2.5G — — — Yes Yes Yes Yes
OC-192 Yes — Yes ————
OC-48 Yes Yes Yes ————
OC-192 ITU — — — Yes Yes Yes Yes
OC-48 ITU — — — Yes Yes Yes Yes
Table 13-6 Client-to-Client Card Combinations for Provisionable Patchcords
Client Cards
MXP_2.5G_10G/
TXP_MR_10G TXP(P)_MR_2.5G
MXP_2.5G_10E/
TXP_MR_10E
MXP_2.5G_10G/
TXP_MR_10G
Yes — Yes
TXP(P)_MR_2.5G —Yes—
MXP_2.5G_10E/
TXP_MR_10E
Yes — Yes
Table 13-7 Trunk-to-Trunk Card Combinations for Provisionable Patchcords
Trunk Cards
MXP_2.5G_10G/
TXP_MR_10G TXP(P)_MR_2.5G
MXP_2.5G_10E/
TXP_MR_10E
MXP_2.5G_10G/
TXP_MR_10G
Yes — Yes
TXP(P)_MR_2.5G —Yes—
MXP_2.5G_10E/
TXP_MR_10E
Yes — Yes
