13-19
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Chapter 13 Management Network Connectivity
13.2.8 Scenario 8: Dual GNEs on a Subnet
Figure 13-14 Scenario 8: Dual GNEs on the Same Subnet
Figure 13-15 shows a network with dual GNEs on different subnets.
115275
Remote CTC
10.10.20.10
10.10.20.0/24
10.10.10.0/24
Interface 0/0
10.10.20.1
Router A
Interface 0/1
10.10.10.1
ONS 15454 SDH
10.10.10.100/24
ONS 15454 SDH
10.10.10.250/24
ONS 15454 SDH
10.10.10.150/24
ONS 15454 SDH
10.10.10.200/24
Local/Craft CTC
192.168.20.20
Ethernet
SDH
