SDH Topologies and Upgrades
This chapter explains Cisco ONS 15454 SDH topologies and upgrades. To provision topologies, refer to
the Cisco ONS 15454 SDH Procedure Guide.
Chapter topics include:
• 12.1 SDH Rings and TCC2/TCC2P Cards, page 12-1
• 12.2 Multiplex Section-Shared Protection Rings, page 12-2
• 12.3 Subnetwork Connection Protection, page 12-13
• 12.4 Dual Ring Interconnect, page 12-18
• 12.5 Subtending Rings, page 12-25
• 12.6 Linear ADM Configurations, page 12-27
• 12.7 Extended SNCP Mesh Networks, page 12-28
• 12.8 Four Node Configurations, page 12-30
• 12.9 STM-N Speed Upgrades, page 12-30
12.1 SDH Rings and TCC2/TCC2P Cards
Table 12-1 shows the SDH rings that can be created on each ONS 15454 SDH node using redundant
TCC2/TCC2P cards.
Table 12-1 ONS 15454 SDH Rings with Redundant TCC2/TCC2P Cards
Ring Type Maximum Rings per Node
MS-SPRings
1
1. MS-SPRing = multiplex section-shared protection ring
5
2-Fiber MS-SPRings 5
4-Fiber MS-SPRings 1
SNCP with RS-DCC 34
2 3
2. Total RS-DCC usage must be equal to or less than 84 RS-DCCs.
3. See the “12.3 Subnetwork Connection Protection” section on page 12-13.
SNCP with MS-DCC 14
4 5
SNCP with MS-DCC and
RS-DCC
26
