10-4
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Chapter 10 Timing
10.3 Synchronization Status Messaging
G812T 3 Transit node clock traceable
G812L 4 Local node clock traceable
SETS 5 Synchronous equipment
DUS 6 Do not use for timing synchronization
Table 10-1 SDH SSM Message Set (continued)
Message Quality Description
