Chapter 8 Cisco Transport Controller Operation
8.5.2 Network View
8.5.2 Network View
Network view allows you to view and manage ONS 15454 SDHs that have DCC connections to the node
that you logged into and any login node groups you selected (Figure 8-6).
Figure 8-6 CTC Network View
Note Nodes with DCC connections to the login node do not appear if you checked the Disable Network
Discovery check box in the Login dialog box.
Inventory Provides inventory information (part number,
serial number, CLEI codes) for cards installed
in the node. Allows you to delete and reset
cards.
—
Maintenance Performs maintenance tasks for the node. Database, Ether Bridge, OSI,
MS-SPRing, Software,
Cross-Connect, Overhead XConnect,
Protection, Diagnostic, Timing,
Audit, RIP Routing Table, Routing
Table, Test Access, DWDM
Table 8-9 Node View Tabs and Subtabs (continued)
Tab Description Subtabs
102027
Bold letters indicate
login node, asterisk
indicates topology host
Icon color indicates
node status
Dots indicate
selected node
