5-3
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Chapter 5 Ethernet Cards
5.1.2 Card Compatibility
5.1.2 Card Compatibility
Table 5-2 lists the CTC software compatibility for each Ethernet card.
Note "Yes" indicates that this card is fully or partially supported by the indicated software release. Refer to
the individual card reference section for more information about software limitations for this card.
5.2 E100T-G Card
Note For specifcations, see the “A.7.1 E100T-G Card Specifications” section on page A-44.
The ONS 15454 SDH uses E100T-G cards for Ethernet (10 Mbps) and Fast Ethernet (100 Mbps). Each
card provides 12 switched, IEEE 802.3-compliant, 10/100BaseT Ethernet ports that can independently
detect the speed of an attached device (autosense) and automatically connect at the appropriate speed.
CE-100T-8 The CE-100T-8 card provides eight IEEE-compliant,
10/100-Mbps ports and is compatible with the
XC-VXL-2.5G, XC-VXL-10G, and XC-VXC-10G
cards.
See the “5.9 CE-100T-8 Card”
section on page 5-19.
CE-1000-4 The CE-1000-4 card provides four IEEE-compliant,
1000-Mbps ports. The CE-1000-4 card can operate
with the XC10G, XC-VXC-10G, XC-VXL-10G, or
XC-VXL-2.5G cross-connect cards.
See the “5.10 CE-1000-4
Card” section on page 5-22.
Table 5-1 Ethernet Cards for the ONS 15454 SDH (continued)
Card Port Description For Additional Information...
Table 5-2 Ethernet Card Software Compatibility
Ethernet
Cards R3.0.1 R3.1 R3.2 R3.3 R3.4 R4.0 R4.1 R4.5
1
1. DWDM-only release.
R4.6 R4.7
1
R5.0 R6.0 R7.0
E100T-G
Ye s Ye s Yes Yes Yes Ye s Yes — Yes — Ye s Yes Yes
E1000-2-G
Ye s Ye s Yes Yes Yes Ye s Yes — Yes — Ye s Yes Yes
G1000-4
— — Yes Yes Yes Yes Yes — Yes — Yes Yes Yes
G1K-4
— — Yes Yes Yes Yes Yes — Yes — Yes Yes Yes
ML100T-12
—————YesYes—Yes—YesYesYes
ML100X-8
—————— — ————YesYes
ML1000-2
—————YesYes—Yes—YesYesYes
CE-100T-8
—————— — ————YesYes
CE-1000-4
—————— — —————Yes
