CHAPTER
5-1
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
5
Ethernet Cards
Note The terms "Unidirectional Path Switched Ring" and "UPSR" may appear in Cisco literature. These terms
do not refer to using Cisco ONS 15xxx products in a unidirectional path switched ring configuration.
Rather, these terms, as well as "Path Protected Mesh Network" and "PPMN," refer generally to Cisco's
path protection feature, which may be used in any topological network configuration. Cisco does not
recommend using its path protection feature in any particular topological network configuration.
The Cisco ONS 15454 SDH integrates Ethernet into a SDH time-division multiplexing (TDM) platform.
This chapter describes the Cisco ONS 15454 SDH E-Series Ethernet cards, G1000-4 Ethernet cards, the
G-1K-4 Ethernet card, ML-Series Ethernet cards, and the CE-Series cards. For Ethernet application
information, see the Ethernet Card Software Feature and Configuration Guide for the Cisco ONS 15454,
Cisco ONS 15454 SDH, and Cisco ONS 15327.
Chapter topics include:
• 5.1 Ethernet Card Overview, page 5-1
• 5.2 E100T-G Card, page 5-3
• 5.3 E1000-2-G Card, page 5-6
• 5.4 G1000-4 Card, page 5-9
• 5.5 G1K-4 Card, page 5-11
• 5.6 ML100T-12 Card, page 5-13
• 5.7 ML100X-8 Card, page 5-15
• 5.8 ML1000-2 Card, page 5-17
• 5.9 CE-100T-8 Card, page 5-19
• 5.10 CE-1000-4 Card, page 5-22
• 5.11 Ethernet Card GBICs and SFPs, page 5-25
5.1 Ethernet Card Overview
The card overview section summarizes the Ethernet card functions and provides the software
compatibility for each Ethernet card.
