4-4
Cisco ONS 15454 SDH Reference Manual, R7.0
October 2008
Chapter 4 Optical Cards
4.1.2 Card Compatibility
Note "Yes" indicates that this card is fully or partially supported by the indicated software release. Refer to
the individual card reference section for more information about software limitations for this card.
Table 4-2 Optical Card Software Release Compatibility
Optical Card R2.2.1 R2.2.2 R3.0.1 R3.1 R3.2 R3.3 R3.4 R4.0 R4.1 R4.5 R4.6 R4.7 R5.0 R6.0 R7.0
OC3 IR 4/STM1 SH
1310
Yes Yes Yes Yes Ye s Ye s Yes Ye s Yes — Yes — Yes Yes Yes
OC3 IR /STM1 SH
1310-8
— — — — — — — Yes Yes — Yes — Yes Yes Yes
OC12 IR/STM4 SH
1310
Yes Yes Yes Yes Ye s Ye s Yes Ye s Yes — Yes — Yes Yes Yes
OC12 LR/STM4 LH
1310
Yes Yes Yes Yes Ye s Ye s Yes Ye s Yes — Yes — Yes Yes Yes
OC12 LR/STM4 LH
1550
Yes Yes Yes Yes Ye s Ye s Yes Ye s Yes — Yes — Yes Yes Yes
OC12 IR/STM4 SH
1310-4
— — — — — YesYesYes Yes— Yes— YesYesYes
OC48 IR/STM16 SH
AS 1310
— — — YesYes YesYesYes Yes— Yes— YesYesYes
OC48 LR/STM16 LH
AS 1550
— — — YesYes YesYesYes Yes— Yes— YesYesYes
OC48 ELR/STM16 EH
100 GHz
Yes Yes Yes Yes Ye s Ye s Yes Ye s Yes — Yes — Yes Yes Yes
OC48 ELR 200 GHz
Yes Yes Yes Yes Ye s Ye s Yes Ye s Yes — Yes — Yes Yes Yes
OC192 SR/STM64 IO
1310
— — — — — — — Yes Yes — Yes — Yes Yes Yes
OC192 IR/STM64 SH
1550
— — — — — — — Yes Yes — Yes — Yes Yes Yes
OC192 LR/STM64 LH
1550
(15454-OC192LR1550)
— — — YesYes YesYesYes Yes— Yes— YesYesYes
OC192 LR/STM64 LH
1550
(15454-OC192-LR2)
— — — — — — — Yes Yes — Yes — Yes Yes Yes
OC192 LR/STM64 LH
ITU 15xx.xx
— — — — — — — Yes Yes — Yes — Yes Yes Yes
15454_MRC-12
— — — —— ——— —————YesYes
OC192SR1/STM64IO
Short Reach/
OC192/STM64 Any
Reach
1
1. These cards are designated as STM64-XFP in CTC
— — — —— ——— —————YesYes
