Chapter 3 Electrical Cards
3.17 MIC-A/P FMEC
7 ALMINP2 N Alarm input pair 3, reports closure on connected wires White/brown
8 ALMINP2 P Alarm input pair 3, reports closure on connected wires Brown/white
9 ALMINP3 N Alarm input pair 4, reports closure on connected wires White/gray
10 ALMINP3 P Alarm input pair 4, reports closure on connected wires Gray/white
11 EXALM0 N External customer alarm 1 Red/blue
12 EXALM0 P External customer alarm 1 Blue/red
13 GND Frame ground —
14 EXALM1 N External customer alarm 2 Red/orange
15 EXALM1 P External customer alarm 2 Orange/red
16 EXALM2 N External customer alarm 3 Red/green
17 EXALM2 P External customer alarm 3 Green/red
18 EXALM3 N External customer alarm 4 Red/brown
19 EXALM3 P External customer alarm 4 Brown/red
20 EXALM4 N External customer alarm 5 Red/gray
21 EXALM4 P External customer alarm 5 Gray/red
22 EXALM5 N External customer alarm 6 Black/blue
23 EXALM5 P External customer alarm 6 Blue/black
24 EXALM6 N External customer alarm 7 Black/orange
25 EXALM6 P External customer alarm 7 Orange/black
26 GND Frame ground —
27 EXALM7 N External customer alarm 8 Black/green
28 EXALM7 P External customer alarm 8 Green/black
29 EXALM8 N External customer alarm 9 Black/brown
30 EXALM8 P External customer alarm 9 Brown/black
31 EXALM9 N External customer alarm 10 Black/gray
32 EXALM9 P External customer alarm 10 Gray/black
33 EXALM10 N External customer alarm 11 Amber/blue
34 EXALM10 P External customer alarm 11 Blue/Amber
35 EXALM11 N External customer alarm 12 Amber/orange
36 EXALM11 P External customer alarm 12 Orange/Amber
37 ALMOUP0 N Normally open output pair 1 White/blue
38 ALMOUP0 P Normally open output pair 1 Blue/white
39 GND Frame ground —
40 ALMOUP1 N Normally open output pair 2 White/orange
41 ALMOUP1 P Normally open output pair 2 Orange/white
42 ALMOUP2 N Normally open output pair 3 White/green
Table 3-16 Alarm Interface Pinouts on the MIC-A/P DB-62 Connector (continued)
Pin No. Signal Name Signal Description Color
