5-5
Cisco Content Services Switch Routing and Bridging Configuration Guide
OL-4580-01
Chapter 5 Configuring Routing Information Protocol
Showing RIP Configurations
Showing RIP Configurations
Use the show rip command to show a RIP configuration for one IP address or all
IP addresses configured in the CSS. This command provides the following options
and variables:
• show rip - Displays RIP configurations for all interfaces
• show rip ip_address - Displays a single RIP interface entry
• show rip globals - Displays RIP global statistics
• show rip statistics - Displays RIP interface statistics for all interfaces
• show rip statistics ip_address - Displays RIP interface statistics for a
specific interface
Table 5-2 describes the fields in the show rip command output.
Table 5-2 Field Descriptions for the show rip Command
Field Description
IP Address The advertised RIP interface address.
State The operational state of the RIP interface.
RIP Send The RIP version that the interface sends. The possible field
values are as follows:
• none - Do not send RIP packets
• RIPv1 - Send RIP version 1 packets only
• RIPv2 - Send RIP version 2 packets only (default)
RIP Recv The RIP version that the interface receives. The possible
values are as follows:
• both - Receive both version 1 and version 2 (default)
• none - Receive no RIP packets
• Ripv1 - Receive RIP version 1 packets only
• Ripv2 - Receive RIP version 2 packets only
Default Metric The default metric used for advertising the RIP interface.
