Cisco ME 3400 Ethernet Access Switch Hardware Installation Guide
OL-7677-04
Chapter 1 Product Overview
Front Panel Description
Table 1-1 describes the switch models.
Front Panel Description
The switch front panel includes the 10/100 ports or dual-purpose ports (that you can configure as either
10/100/1000 Ethernet ports that use RJ-45 connectors or for SFP modules), dedicated SFP module ports,
switch LEDs, power connectors, and the console port.
The front panels are described in these sections:
• Cisco ME 3400-24TS AC and DC Switches Front Panel, page 1-3
• Cisco ME 3400-24FS Switch AC Switch Front Panel, page 1-4
• Cisco ME 3400G-12CS AC and DC Switches Front Panel, page 1-4
• Cisco ME 3400G-2CS Switch Front Panel, page 1-5
• 10/100 Ports (Only the Cisco ME-3400-24TS Switches), page 1-6
• Dual-Purpose Ports (Only the Cisco ME 3400G-12CS and Cisco ME 3400G-2CS Switches),
page 1-6
• SFP Module Ports, page 1-7
• LEDs, page 1-8
• Console Port, page 1-11
Table 1-1 Cisco ME 3400 Switch Models
Switch Model Part Number Description
Cisco ME 3400-24TS-AC ME-3400-24TS-A 24 10/100 FastEthernet ports and 2 small form-factor pluggable (SFP)
module ports, AC power
Cisco ME 3400-24TS-DC ME-3400-24TS-D 24 10/100 FastEthernet ports and 2 SFP module ports, DC power
Cisco ME-3400-24FS-A ME-3400-24FS-A 24 100BASE-FX SFP module ports and 2 Gigabit Ethernet SFP module
ports, AC power
Cisco ME 3400G-12CS-AC ME-3400G-12CS-A 12 dual-purpose ports and 4 SFP module ports, AC power
Cisco ME 3400G-12CS-DC ME-3400G-12CS-D 12 dual-purpose ports and 4 SFP module ports, DC power
Cisco ME 3400G-2CS ME 3400G-2CS 2 dual-purpose ports and 2 SFP module ports, AC power
