Cisco SFS 7000P and SFS 7000D InfiniBand Server Switches Hardware Installation Guide November 2006 Corporate Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 USA http://www.cisco.
THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.
CONTENTS Audience vii Organization vii Conventions viii Related Documentation xiv Obtaining Documentation xiv Cisco.
Contents Administrative Features 1-5 Real-Time Clock 1-5 Latency 1-5 Nonvolatile Memory 1-5 Diagnostics 1-5 CHAPTER 2 Preparation for Installation Safety 2-1 2-1 Site Requirements 2-1 Temperature 2-2 Humidity 2-2 Altitude 2-2 Dust and Particles 2-3 Corrosion 2-3 Electromagnetic and Radio Frequency Interference Shock and Vibration 2-4 Power Source Interruptions 2-4 Preventing Electrostatic Discharge Damage 2-4 Air Flow 2-5 Power Requirements 2-5 Site Preparation Checklist CHAPTER 3 Installing the
Contents Connecting Ethernet Management Devices Managing the System CHAPTER 4 3-14 3-14 Installing Field Replaceable Units 4-1 Power Supply Modules 4-1 Locating the Power Supply Unit 4-1 Failed Power Supply Modules 4-1 CHAPTER 5 Installing a Power Supply Module 4-2 Removing Power Supply Modules 4-4 Managing the Switch 5-1 LEDs 5-1 Chassis Status LEDs 5-1 InfiniBand Port LEDs 5-3 Power Supply LEDs 5-3 Managing the System with Element Manager Using the Summary Tab 5-5 Using the Power Supplies
Contents APPENDIX A Specifications and Compliance Certifications Chassis and Management Interface A-1 Electrical Specifications A-2 APPENDIX B Acronyms and Abbreviations A-1 3 Cisco SFS 7000P and SFS 7000D InfiniBand Server Switches Hardware Installation Guide vi 78-10853-01
Preface This preface describes who should read the Cisco SFS 7000P and SFS 7000D InfiniBand Server Switches Hardware Installation Guide, how it is organized, and its document conventions. Audience Only trained and qualified service personnel (as defined in IEC 60950 and AS/NZS3260) should install, replace, or service the equipment described in this publication.
Preface Conventions Conventions This publication uses the following conventions: Convention Description boldface font Commands, command options, and keywords are in boldface. italic font Arguments for which you supply values are in italics. [ ] Elements in square brackets are optional. {x|y|z} Alternative keywords are grouped in braces and separated by vertical bars. [x|y|z] Optional alternative keywords are grouped in brackets and separated by vertical bars.
Preface Conventions Warnings use the following conventions: Warning IMPORTANT SAFETY INSTRUCTIONS This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. Use the statement number provided at the end of each warning to locate its translation in the translated safety warnings that accompanied this device.
Preface Conventions Avvertenza IMPORTANTI ISTRUZIONI SULLA SICUREZZA Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare infortuni alle persone. Prima di intervenire su qualsiasi apparecchiatura, occorre essere al corrente dei pericoli relativi ai circuiti elettrici e conoscere le procedure standard per la prevenzione di incidenti.
Preface Conventions Cisco SFS 7000P and SFS 7000D InfiniBand Server Switches Hardware Installation Guide OL-10853-01 xi
Preface Conventions Aviso INSTRUÇÕES IMPORTANTES DE SEGURANÇA Este símbolo de aviso significa perigo. Você se encontra em uma situação em que há risco de lesões corporais. Antes de trabalhar com qualquer equipamento, esteja ciente dos riscos que envolvem os circuitos elétricos e familiarize-se com as práticas padrão de prevenção de acidentes. Use o número da declaração fornecido ao final de cada aviso para localizar sua tradução nos avisos de segurança traduzidos que acompanham o dispositivo.
Preface Conventions Cisco SFS 7000P and SFS 7000D InfiniBand Server Switches Hardware Installation Guide OL-10853-01 xiii
Preface Related Documentation Related Documentation For more information about the Cisco SFS 7000 switch product family, refer to these publications: • Cisco SFS 7000D InfiniBand Server Switch Installation and Configuration Note • Cisco SFS 7000P InfiniBand Server Switch Installation and Configuration Note • Cisco SFS 7008P InfiniBand Server Switch Installation and Configuration Note • Cisco SFS 7008P InfiniBand Server Switch Hardware Installation Guide • Cisco SFS 7000 Series Product Family Chass
Preface Documentation Feedback You can access international Cisco websites at this URL: http://www.cisco.com/public/countries_languages.shtml Product Documentation DVD The Product Documentation DVD is a library of technical product documentation on a portable medium. The DVD enables you to access installation, configuration, and command guides for Cisco hardware and software products.
Preface Product Alerts and Field Notices To see security advisories, security notices, and security responses as they are updated in real time, you can subscribe to the Product Security Incident Response Team Really Simple Syndication (PSIRT RSS) feed. Information about how to subscribe to the PSIRT RSS feed is found at this URL: http://www.cisco.com/en/US/products/products_psirt_rss_feed.html Reporting Security Problems in Cisco Products Cisco is committed to delivering secure products.
Preface Obtaining Technical Assistance Obtaining Technical Assistance Cisco Technical Support provides 24-hour-a-day award-winning technical assistance. The Cisco Technical Support & Documentation website on Cisco.com features extensive online support resources. In addition, if you have a valid Cisco service contract, Cisco Technical Assistance Center (TAC) engineers provide telephone support. If you do not have a valid Cisco service contract, contact your reseller.
Preface Obtaining Additional Publications and Information Submitting a Service Request Using the online TAC Service Request Tool is the fastest way to open S3 and S4 service requests. (S3 and S4 service requests are those in which your network is minimally impaired or for which you require product information.) After you describe your situation, the TAC Service Request Tool provides recommended solutions.
Preface Obtaining Additional Publications and Information • The Cisco Product Quick Reference Guide is a handy, compact reference tool that includes brief product overviews, key features, sample part numbers, and abbreviated technical specifications for many Cisco products that are sold through channel partners. It is updated twice a year and includes the latest Cisco channel product offerings. To order and find out more about the Cisco Product Quick Reference Guide, go to this URL: http://www.cisco.
Preface Obtaining Additional Publications and Information Cisco SFS 7000P and SFS 7000D InfiniBand Server Switches Hardware Installation Guide xx OL-10853-01
1 C H A P T E R Product Overview The Cisco SFS 7000P and SFS 7000D Server Switches provide high-class data center infrastructure that interconnect discreet server resources together into high-performance, low-latency fabric switches.
Chapter 1 Product Overview Switch Connectors Cisco SFS 7000D Server Switch Power Supply 2 180600 Figure 1-2 Switch Connectors The Cisco SFS 7000P Server Switch uses the following connectors: • Twenty-four 10-Gbps 4x copper InfiniBand ports for server and interswitch connectivity • One 10/100 Ethernet RJ-45 management-Ethernet port for out-of-band management • One RJ-45 console port used to configure and monitor the Cisco SFS 7000P Server Switch The Cisco SFS 7000D Server Switch uses the followi
Chapter 1 Product Overview System Features LEDs The Cisco SFS 7000P and SFS 7000D Server Switches feature the following LEDs: • Chassis LEDs—Show overall system status, power status, and fan status. LEDs and their use are described in the “Chassis Status LEDs” section on page 5-1. • InfiniBand Port LEDs—Show link status, diagnostics, and network traffic. LEDs and their uses are described in the “InfiniBand Port LEDs” section on page 5-3.
Chapter 1 Product Overview System Features Scalability The embedded subnet manager running on the Cisco SFS 7000P and SFS 7000D Server Switches can manage up to 1,152 hosts. High Availability High availability operates at the hardware, port, and fabric level. These features are described below. Hardware High availability at the hardware level means that the Cisco SFS 7000P and SFS 7000D Server Switches feature hot-swappable redundant power and cooling.
Chapter 1 Product Overview Administrative Features Nonblocking Architecture The Cisco SFS 7000P and SFS 7000D Server Switches provide nonblocking switch element architecture with full bisectional bandwidth for the switch chassis.
Chapter 1 Product Overview Administrative Features Cisco SFS 7000P and SFS 7000D InfiniBand Server Switches Hardware Installation Guide 1-6 OL-10853-01
C H A P T E R 2 Preparation for Installation Planning a proper location for the Cisco SFS 7000P and SFS 7000D Server Switches and the proper layout of your equipment rack is essential for successful system operation.
Chapter 2 Preparation for Installation Site Requirements The switch requires a dry, clean, well-ventilated, and air-conditioned environment. To ensure normal operation, maintain ambient airflow. If the airflow is blocked or restricted, or if the intake air is too warm, an overtemperature condition can occur. The switch environmental monitor can then shut down the system to protect the system components. Multiple switches can be rack-mounted with little or no clearance above and below the chassis.
Chapter 2 Preparation for Installation Site Requirements Dust and Particles Exhaust fans cool power supplies and system fan trays cool systems by drawing in air and exhausting air out through various openings in the chassis. However, fans also ingest dust and other particles, causing contaminant buildup in the system and increased internal chassis temperature.
Chapter 2 Preparation for Installation Site Requirements If you use twisted-pair cable in your plant wiring with sufficient distribution of grounding conductors, the plant wiring is unlikely to emit radio interference. If you exceed the recommended distances, use a high-quality twisted-pair cable with one ground conductor for each data signal when applicable.
Chapter 2 Preparation for Installation Power Requirements Air Flow Note The air flows from front to back through the Cisco SFS 7000P and SFS 7000D Server Switches. (See Figure 2-1.) Figure 2-1 Air Flow Direction in the Cisco SFS 7000P and SFS 7000D Server Switches 181224 Back Front Follow these guidelines to ensure proper airflow: • Maintain ambient airflow throughout the data center to ensure normal operation.
Chapter 2 Preparation for Installation Site Preparation Checklist Site Preparation Checklist Table 2-1 lists the site planning activities that you should perform prior to installing the Cisco SFS 7000P and SFS 7000D Server Switches. Completing each activity helps ensure a successful switch installation. Table 2-1 Site Planning Checklist Task No.
C H A P T E R 3 Installing the Switches This chapter describes how to install and manage the Cisco SFS 7000P and SFS 7000D Server Switches hardware and contains these sections: • Safety, page 3-2 • Pre-installation Instructions, page 3-2 • Rack-Mounting the Switches, page 3-3 • Configuring Basic Connectivity, page 3-7 • Connecting Network Devices, page 3-11 • Managing the System, page 3-14 Warning During this procedure, wear grounding wrist straps to avoid ESD damage to the card.
Chapter 3 Installing the Switches Safety Safety Warning Voltage is present on the backplane when the system is operating. To reduce risk of an electric shock, keep hands and fingers out of the power supply bays and backplane areas. Statement 166 Warning This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the absence of a suitably installed ground conductor.
Chapter 3 Installing the Switches Rack-Mounting the Switches Rack-Mounting the Switches Warning Two people are required to lift the chassis. Grasp the chassis underneath the lower edge and lift with both hands. To prevent injury, keep your back straight and lift with your legs, not your back. To prevent damage to the chassis and components, never attempt to lift the chassis with the handles on the power supplies or on the interface processors, or by the plastic panels on the front of the chassis.
Chapter 3 Installing the Switches Rack-Mounting the Switches The MAC address and GUID number are available on sticker labels placed on top of the switch. Step 4 Check the slot in the rack for sufficient clearance.
Chapter 3 Installing the Switches Rack-Mounting the Switches Step 4 Check the rack for clearance for the switch. The switch can be installed either directly on top of another device or be suspended from the rack posts. Step 5 Attach the remaining two rack brackets to your rack. a. Position a bracket toward the back of the rack with the flange facing away from the rack. The flange should go around the outside of the rack post, as shown in Figure 3-3.
Chapter 3 Installing the Switches Rack-Mounting the Switches Step 7 Carefully push the switch unit into the rack, as shown in Figure 3-5. If the brackets do not slide easily, the alignment might be off. Pull the switch back toward you, and realign the brackets. Sliding the Switch Into the Rack 144954 Figure 3-5 Step 8 Maintain at least six inches between the cooling vents and any obstructions. Step 9 Secure the switch with your screws through the front of the rack, as shown in Figure 3-6.
Chapter 3 Installing the Switches Configuring Basic Connectivity Step 2 Attach the rack bracket that has screw holes to the sides of the switch by using the screws provided. When attaching the rack bracket, the flanges of the rack bracket should be facing away from the switch. (See Figure 3-2.) Step 3 Attach the rack brackets to their counterparts before inserting the switch into the rack. Step 4 Insert the switch into the rack with the rack bracket attached.
Chapter 3 Installing the Switches Configuring Basic Connectivity find out which address was allocated by logging to the CLI on the serial console and using the show interface mgmt-eth command. See the Cisco SFS 7000 Series Product Family Command Reference for further details on using CLI commands. Use the IP address, to Telnet to the Cisco SFS 7000D Server Switch.
Chapter 3 Installing the Switches Configuring Basic Connectivity You can connect the serial console port to a PC serial port for local administrative access to the switch. A terminal emulation software product, such as HyperTerminal, makes communication between your switch and your PC possible during setup and configuration.
Chapter 3 Installing the Switches Configuring Basic Connectivity Step 8 Set the default gateway for the management interface. See your system administrator for a gateway address. SFS-7000D(config-if-mgmt-ethernet)# gateway ip address Step 9 Enable the management interface by entering the no shutdown command. SFS-7000D(config-if-mgmt-ethernet)# no shutdown Step 10 Save the configuration to preserve it between reboots.
Chapter 3 Installing the Switches Connecting Network Devices Figure 3-9 Power Connector Locations for the Cisco SFS 7000P Server Switch Power connector 144945 Power connector Figure 3-10 Power Connector Locations for the Cisco SFS 7000D Server Switch Power connector 180601 Power connector Step 4 Connect the other end of each AC power cable into a 90-to 264-VAC power outlet operating between 47 Hz and 63 Hz. The switch automatically starts and boots up. Use the correct external power source.
Chapter 3 Installing the Switches Connecting Network Devices Connecting InfiniBand Devices Warning Invisible laser radiation may be emitted from the end of the unterminated fiber cable or connector. Do not view directly with optical instruments. Viewing the laser output with certain optical instruments (for example, eye loupes, magnifiers, and microscopes) within a distance of 100 mm may pose an eye hazard.
Chapter 3 Installing the Switches Connecting Network Devices Step 1 Connect InfiniBand cables from the host to the InfiniBand switch. a. To connect an InfiniBand cable, push the connector into the interface until you hear or feel a click. Figure 3-13 shows an InfiniBand cable with a pinch connector, and Figure 3-14 shows an InfiniBand cable with a pull connector.
Chapter 3 Installing the Switches Managing the System Removing a Pinch Connector 13 Press here Press here c. 144962 Figure 3-15 To remove a cable with a pull connector, grasp the connector with one hand and push it toward the port, then pull the latch away from the port with your other hand and gently move the connector back and forth and away from the port. (See Figure 3-16.
Chapter 3 Installing the Switches Managing the System • Command-Line Interface (CLI)—A text-based interface accessible through a direct serial connection, Telnet over IP, or SSH over IP • Chassis Manager (GUI)—A web-based graphical user interface • Element Manager (GUI)—A graphical interface installed on a workstation, accessible over IP See the Cisco SFS 7000 Series Product Family Command Reference, Cisco SFS 7000 Series Product Family Chassis Manager User Guide, and the Cisco SFS 7000 Series Produ
Chapter 3 Installing the Switches Managing the System Cisco SFS 7000P and SFS 7000D InfiniBand Server Switches Hardware Installation Guide 3-16 OL-10853-01
C H A P T E R 4 Installing Field Replaceable Units This chapter describes how to install the following FRUs in the Cisco SFS 7000P and SFS 7000D Server Switches: • Power Supply Modules, page 4-1 • Installing a Power Supply Module, page 4-2 • Removing Power Supply Modules, page 4-4 Power Supply Modules The Cisco SFS 7000P and SFS 7000D Server Switches power supply modules are hot-swappable. You can add a second module without powering off a switch.
Chapter 4 Installing Field Replaceable Units Installing a Power Supply Module Installing a Power Supply Module Warning Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. Statement 1034 Caution Never place your hand inside an empty module bay or anywhere inside the Cisco SFS 7000P and SFS 7000D Server Switches.
Chapter 4 Installing Field Replaceable Units Installing a Power Supply Module Step 3 Remove the power supply module if one is in place by pulling on the black handle. (See Figure 4-2.) Removing the Power Supply from the Switch 154011 Figure 4-2 Step 4 Insert the new power supply module into the open slot until it is fully seated. You might need to push the unit with your thumbs to ensure that it is seated completely in the bay.
Chapter 4 Installing Field Replaceable Units Removing Power Supply Modules Removing Power Supply Modules Caution Do not remove the power supply module without first removing the screws. Use a number 1 Phillips or a slotted screwdriver. To remove a power supply module, follow these steps: Step 1 Make sure you have a number 1 Phillips or a slotted screwdriver to disengage the fasteners. Step 2 Ground yourself appropriately.
C H A P T E R 5 Managing the Switch This chapter describes how to manage the Cisco SFS 7000P and SFS 7000D Server Switches hardware.
Chapter 5 Managing the Switch LEDs Figure 5-1 Front View of Cisco SFS 7000P Server Switch Showing Chassis Status LED Bi-color chassis status LED 180716 Cisco Systems Power Supply 1 Figure 5-2 Front View of Cisco SFS 7000D Server Switch Showing Chassis Status LED Cisco Systems Status 180718 SFS-7000D Power Supply 1 Bi-color chassis status LED Figure 5-3 Rear View of Cisco SFS 7000P Server Switch Showing Chassis Status LEDs Green chassis status LED Figure 5-4 180717 Yellow chassis status
Chapter 5 Managing the Switch LEDs InfiniBand Port LEDs The InfiniBand port LED is located next to each InfiniBand port. The InfiniBand LED represents the logical link and the logical link activity. For InfiniBand port LED locations. See Figure 5-5 for the Cisco SFS 7000P Server Switch and Figure 5-6 for the Cisco SFS 7000D Server Switch.
Chapter 5 Managing the Switch Managing the System with Element Manager Power Supply and Fan LEDs Location 154012 Figure 5-7 ! Power Supply LEDs Table 5-3 Power Supply Module LEDs Color Indication Green (off) No DC input. Green (solid) AC connected, DC output OK. Yellow (off) No failure on the power supply. Yellow (solid) Operator intervention required. Failure detected within the power supply.
Chapter 5 Managing the Switch Managing the System with Element Manager Using the Summary Tab Use the Summary tab to view the status of the power, fans, and temperature sensors simultaneously. (See Figure 5-8.) The Summary tab has the following fields: • Power – A green check indicates that at least one power source is connected and functioning properly. – A red check indicates that the power supply AC is disconnected.
Chapter 5 Managing the Switch Displaying System Information In the OperStatus field, a status of up indicates that the fan is operating correctly within the power supply module. In the Speed field, the integer represents a percentage. The percentage changes based on the ambient temperature of the unit and increases as the temperature rises. Using the Sensors Tab Use the Sensors tab to view the operating status of the temperature sensor of the system. (See Figure 5-11.
Chapter 5 Managing the Switch Displaying System Information Displaying Fan Information To display information about the fans, enter the show fan command. An oper-status of up means that the fan is operating correctly within the power supply module. In the Speed field, the integer represents a percentage. The percentage changes based on the ambient temperature of the unit and increases as the temperature rises.
Chapter 5 Managing the Switch Displaying System Information Cisco SFS 7000P and SFS 7000D InfiniBand Server Switches Hardware Installation Guide 5-8 OL-10853-01
C H A P T E R 6 Hardware Diagnostic Tests This chapter describes how to run diagnostic tests on the hardware for the Cisco SFS 7000P and SFS 7000D Server Switches, and it contains the following sections: • About Diagnostic Tests, page 6-1 • Displaying Hardware Errors, page 6-8 About Diagnostic Tests Hardware diagnostic tests can be performed through the CLI or the Element Manager GUI.
Chapter 6 Hardware Diagnostic Tests About Diagnostic Tests Running Card Self-Test The term cards in this section refers to fabric controllers, management I/O modules, node cards, and the chassis ID module. Fans and power supplies are not included in the card tests; they can be tested through the standard chassis test or as individual components.
Chapter 6 Hardware Diagnostic Tests About Diagnostic Tests Running Chassis Self-Test The following tests are available to locate and diagnose the chassis: • LED • Standard • Extended • Extended Memory The example below shows how to run a chassis standard test. Note The sample text in the steps below shows command output for the Cisco SFS 7000P Server Switch. For the Cisco SFS 7000D Server Switch, you would see a similar display.
Chapter 6 Hardware Diagnostic Tests About Diagnostic Tests Step 3 Display any errors on individual components by entering the show diag post command.
Chapter 6 Hardware Diagnostic Tests About Diagnostic Tests Power Supply Numbers on the Cisco SFS 7000P and SFS 7000D Server Switches 181046 Figure 6-1 Power Supp ly 1 Power Supp ly 2 Enter the show diagnostic fan command.
Chapter 6 Hardware Diagnostic Tests Running Power Supply Tests SFS-7000P# show diag fan ================================================================================ Diagnostic Tests For Fan ================================================================================ module-type : fan module-number : 1 test : self-test iterations : 1 action : start result : success percentage-completed : 100 result-string : Fan Self Test Completed, Final report : Passed=1, Failed=0, Total=1 SFS-7000P# Step 4 Dis
Chapter 6 Hardware Diagnostic Tests Running Power Supply Tests Running a LED Test on the Power Supply You can use the LED test to identify a specific power supply by entering these commands: SFS-7000P> enable SFS-7000P# config SFS-7000P(config)# diag power-supply 1 SFS-7000P(config-diag-power-supply-1)# test led SFS-7000P(config-diag-power-supply-1)# start SFS-7000P(config-diag-power-supply-1)# stop SFS-7000P(config-diag-power-supply-1)# Running a Self-Test on a Power Supply To perform a diagnostic self-
Chapter 6 Hardware Diagnostic Tests Displaying Hardware Errors ================================================================ Fru-Error ================================================================ fru-slot fru-error ---------------------------------------------------------------card(9) none card(10) none card(11) none card(12) none card(13) none card(14) none card(15) none card(17) none fan(1) none fan(2) none fan(3) none fan(4) none power-supply(1) none power-supply(2) none SFS-7000P# Step 6 Reb
Chapter 6 Hardware Diagnostic Tests Displaying Hardware Errors You can also view POST error codes with the show diagnostic post command. This command displays the results of each POST that executes at power-up.
Chapter 6 Hardware Diagnostic Tests Displaying Hardware Errors Cisco SFS 7000P and SFS 7000D InfiniBand Server Switches Hardware Installation Guide 6-10 OL-10853-01
A P P E N D I X A Specifications and Compliance Certifications This appendix describes the Cisco SFS 7000P and SFS 7000D Server Switches specifications and compliance certifications. Chassis and Management Interface Table A-1 lists the general specifications for the Cisco SFS 7000P and SFS 7000D Server Switches.
Appendix A Specifications and Compliance Certifications Electrical Specifications Table A-2 lists the electrical specifications for the Cisco SFS 7000P and SFS 7000D Server Switches.
REVIEW DRAFT—CISCO CONFIDENTIAL A P P E N D I X B Acronyms and Abbreviations Table B-1 defines the acronyms and abbreviations that are used in this publication.
Appendix B Acronyms and Abbreviations REVIEW DRAFT—CISCO CONFIDENTIAL Cisco SFS 7000P and SFS 7000D InfiniBand Server Switches Hardware Installation Guide B-4 OL-10853-01
