Appendix K Router Platform User Interface Reference
PPP/MLP Policy Page
K-86
User Guide for Cisco Security Manager 3.2
OL-16066-01
Endpoint Type The identifier used by the router when transmitting packets on the MLP
bundle:
• [null]—Negotiation is conducted without using an endpoint
discriminator. (No CLI command is generated.)
• Hostname—The hostname of the router. This option is useful when
multiple routers are using the same username to authenticate but have
different hostnames.
• IP—A defined IP address. Enter an address or the name of a
network/host object, or click Select to display an Object Selectors,
page F-593.
• MAC—The MAC address of a specific interface. Enter the name of an
interface or interface role, or click Select to display an Object Selectors,
page F-593.
• None—Negotiation is conducted without using an endpoint
discriminator. (The relevant CLI command is generated, but no endpoint
discriminator is provided.) This option is useful when the router is
connected to a malfunctioning peer that does not handle the endpoint
discriminator properly.
• Phone—An E.164-compliant telephone number. Enter the number in the
field displayed.
• String—A character string. Enter the string in the field displayed.
The default endpoint discriminator is either the globally configured
hostname, or the PAP username or CHAP hostname (depending on the
authentication protocol being used), if you have configured those values on
the PPP tab.
MRRU Local Peer The maximum receive reconstructed unit (MRRU) value of the local peer.
This value represents the maximum size packet that the local router is
capable of receiving.
Valid values range from 128 to 16384 bytes. The default is the maximum
transmission unit (MTU) of the multilink group interface and 1524 bytes for
all other interfaces.
Table K-36 PPP Dialog Box—MLP Tab (Continued)
