PPP Dialog Box—MLP Tab
Use the MLP tab of the PPP dialog box to define Multilink PPP (MLP) parameters
for the selected PPP connection.
Navigation Path
Go to the PPP Dialog Box, page K-78, then click the MLP tab.
Related Topics
• PPP Dialog Box—PPP Tab, page K-80
Field Reference
Table K-36 PPP Dialog Box—MLP Tab
Element Description
Enable Multilink PPP
(MLP)
When selected, MLP is enabled on this PPP connection.
When deselected, MLP is disabled.
Allow Multiple Data
Classes
When selected, enables multiple data classes on the MLP bundle.
Delay-sensitive traffic is placed into Class 1, where it can be interleaved but
never fragmented. Normal data traffic is placed into Class 0, which is subject
to fragmentation just as regular multilink packets are.
When deselected, all traffic is subject to fragmentation.
Enable Interleaving of
Packets Among
Fragments of Larger
Packets
When selected, enables the interleaving of packets among the fragments of
larger packets on the MLP bundle.
Note If you enable interleaving without defining a fragment delay, the
default delay of 30 seconds is configured. This value does not appear
in Security Manager or in the device configuration.
When deselected, interleaving is disabled.
Note Serial interfaces do not support interleaving.
