K-77
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
PPP/MLP Policy Page
Field Reference
Tip To choose which columns to display in the table, right-click a column header, then
select Show Columns. For more information about table display options, see
Table Columns and Column Heading Features, page 3-26.
Table K-33 PPP/MLP Page
Element Description
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
Interface The interface that is configured for PPP/MLP.
Authentication The types of authentication used on the PPP connection.
Authorization The method list used for AAA authorization on the PPP connection.
Multilink Indicates whether Multilink PPP (MLP) is enabled on this PPP connection.
Endpoint The type of default endpoint discriminator to use when negotiating the use
of MLP with the peer.
Multiclass Indicates whether the Multiclass Multilink PPP (MCMP) feature is enabled
on this PPP connection.
Group The number of the multilink-group interface to which the physical link is
restricted.
Interleave Indicates whether the PPP multilink interleave feature is enabled on this PPP
connection.
Add button Opens the PPP Dialog Box, page K-78. From here you can define the
authentication and multilink settings for the PPP connection.
Edit button Opens the PPP Dialog Box, page K-78. From here you can edit the selected
PPP connection.
Delete button Deletes the selected PPP connection from the table.
Save button Saves your changes to the Security Manager server but keeps them private.
Note To publish your changes, click the Submit button on the toolbar.
