Network Router User Manual
Table Of Contents
- Router Platform User Interface Reference
- NAT Policy Page
- Router Interfaces Page
- Advanced Interface Settings Page
- AIM-IPS Interface Settings Page
- Dialer Policy Page
- ADSL Policy Page
- SHDSL Policy Page
- PVC Policy Page
- PPP/MLP Policy Page
- AAA Policy Page
- Accounts and Credential s Policy Page
- Bridging Policy Page
- Clock Policy Page
- CPU Policy Page
- HTTP Policy Page
- Console Policy Page
- VTY Policy Page
- Secure Shell Policy Page
- SNMP Policy Page
- DNS Policy Page
- Hostname Policy Page
- Memory Policy Page
- Secure Device Provisioning Policy Page
- DHCP Policy Page
- NTP Policy Page
- 802.1x Policy Page
- Network Admission Control Policy Page
- Logging Setup Policy Page
- Syslog Servers Policy Page
- Quality of Service Policy Page
- BGP Routing Policy Page
- EIGRP Routing Policy Page
- OSPF Interface Policy Page
- OSPF Process Policy Page
- RIP Routing Policy Page
- Static Routing Policy Page
K-7
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
NAT Policy Page
Field Reference
Tip To choose which columns to display in the table, right-click a column header, then
select Show Columns. For more information about table display options, see
Table Columns and Column Heading Features, page 3-26.
NAT Static Rule Dialog Box
Use the NAT Static Rule dialog box to add or edit static address translation rules.
Navigation Path
Go to the NAT Page—Static Rules Tab, page K-6, then click the Add or Edit
button beneath the table.
Table K-4 NAT Static Rules Tab
Element Description
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
Original Address The original address (and optionally, the subnet mask) that is being
translated.
Translated Address The IP address to which the traffic is translated.
Port Redirection (When the static rule is defined on a port) Information about the port that is
being translated, including the local and global port numbers.
Advanced The advanced options that are enabled.
Add button Opens the NAT Static Rule Dialog Box, page K-7. From here you can create
a static translation rule.
Edit button Opens the NAT Static Rule Dialog Box, page K-7. From here you can edit
the selected static translation rule.
Delete button Deletes the selected static translation rules from the table.
Save button Saves your changes to the Security Manager server but keeps them private.
Note To publish your changes, click the Submit icon on the toolbar.
