K-69
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
PVC Policy Page
Field Reference
PVC Advanced Settings Dialog Box
Use the PVC Advanced Settings dialog box to configure F5 Operation,
Administration, and Maintenance (OAM) functionality on an ATM PVC. OAM is
used to detect connectivity failures at the ATM layer.
Table K-29 Define Mapping Dialog Box
Element Description
IP Options The type of IP protocol mapping to use:
• IP Address—Select this option when using static mapping. Enter the
address or network/host object, or click Select to display an Object
Selectors, page F-593.
If the network you want is not listed, click the Create button in the
selector to display the Network/Host Dialog Box, page F-477. From
here, you can define a network/host object.
• InARP—Inverse ARP. Select this option when using dynamic mapping.
This allows the PVC to resolve its own network addresses without
configuring a static map. Dynamic mappings age out and are refreshed
periodically every 15 minutes by default.
Note InARP can be used only when aal5snap is the defined encapsulation
type for the PVC. See PVC Dialog Box—Settings Tab, page K-59.
Broadcast Options Indicates whether to use this map entry when sending IP broadcast packets
(such as EIGRP updates):
• Broadcast—The map entry is used for broadcast packets.
• No Broadcast—The map entry is used only for unicast packets.
• None—Broadcast options are disabled.
OK button Saves your changes locally on the client and closes the dialog box.
Note To save your changes to the Security Manager server so that they are
not lost when you log out or close your client, click Save on the
source page.
