Appendix K Router Platform User Interface Reference
PVC Policy Page
K-58
User Guide for Cisco Security Manager 3.2
OL-16066-01
Interface Card
(continued)
• NM-1A-E3—A 1-port ATM network module with an E3 link.
• 857 ADSL—Cisco 857 Integrated Service Router with an ADSL
interface.
• 876 ADSL—Cisco 876 Integrated Services Router with an ADSL
interface.
• 877 ADSL—Cisco 877 Integrated Services Router with an ADSL
interface.
• 878 G.SHDSL—Cisco 878 Integrated Services Router with a G.SHDSL
interface.
• 1801 ADSLoPOTS—Cisco 1801 Integrated Services Router that
provides ADSL over POTS.
• 1802 ADSLoISDN—Cisco 1802 Integrated Services Router that
provides ADSL over ISDN.
• 1803 G.SHDSL—Cisco 1803 Integrated Services Router that provides
4-wire G.SHDSL.
Note To ensure proper policy validation, we highly recommend that you
define a value in this field. When you discover a live device, the
correct interface card type will already be displayed. If you did not
perform discovery on a live device, or if Security Manager cannot
detect the type of interface card installed on the device, this field
displays “Unknown”.
Settings tab Defines basic PVC settings, such as the VPI/VCI and encapsulation. See
PVC Dialog Box—Settings Tab, page K-59.
QoS tab Defines ATM traffic shaping and other quality-of-service settings for the
PVC. See PVC Dialog Box—QoS Tab, page K-63.
Protocol tab Defines the IP protocol mappings configured for the PVC (static maps or
Inverse ARP). See PVC Dialog Box—Protocol Tab, page K-67.
Advanced button Defines F5 Operation, Administration, and Maintenance (OAM) settings for
the PVC. See PVC Advanced Settings Dialog Box—OAM Tab, page K-70.
Table K-25 PVC Dialog Box (Continued)
