Appendix K Router Platform User Interface Reference
PVC Policy Page
K-56
User Guide for Cisco Security Manager 3.2
OL-16066-01
PVC Dialog Box
Use the PVC dialog box to configure ATM permanent virtual circuits (PVCs).
Navigation Path
Go to the PVC Policy Page, page K-54, then click the Add or Edit button beneath
the table.
Related Topics
• Defining ATM PVCs, page 15-52
Field Reference
Ta b l e K - 2 5 P VC D i a l o g B o x
Element Description
ATM Interface The ATM interface on which the PVC is defined. Enter the name of an
interface, subinterface, or interface role, or click Select to display an Object
Selectors, page F-593.
If the interface role you want is not listed, click the Create button in the
selector to display the Interface Role Dialog Box, page F-464. From here
you can define an interface role object.
Note We strongly recommend not defining an interface role that includes
ATM interfaces from different interface cards. The different settings
supported by each card type may cause deployment to fail.
