K-55
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
PVC Policy Page
Field Reference
Tip To choose which columns to display in the table, right-click a column header, then
select Show Columns. For more information about table display options, see
Table Columns and Column Heading Features, page 3-26.
Ta b l e K - 2 4 P VC Pa g e
Element Description
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
ATM Interface The ATM interface on which the PVC is defined.
Interface Card The type of device or WAN interface card on which the ATM interface
resides.
PVC ID The Virtual Path Identifier (VPI) and Virtual Channel Identifier (VCI) of the
PVC.
Settings Additional settings configured for the PVC, including encapsulation, the
number of PPPoE sessions, and the VPN service name.
QoS Quality-of-service settings defined for the PVC, such as traffic shaping.
Protocol The IP protocol mappings (static maps or Inverse ARP) configured for the
PVC.
OAM The F5 Operation, Administration, and Maintenance (OAM) loopback,
continuity check, and AIS/RDI definitions configured for the PVC.
OAM-PVC The OAM management cells that are configured for the PVC.
Add button Opens the PVC Dialog Box, page K-56. From here you can define a PVC.
Edit button Opens the PVC Dialog Box, page K-56. From here you can edit the selected
PVC.
Delete button Deletes the selected PVC from the table.
Save button Saves your changes to the Security Manager server but keeps them private.
Note To publish your changes, click the Submit button on the toolbar.
