K-49
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
SHDSL Policy Page
Tip To choose which columns to display in the table, right-click a column header, then
select Show Columns. For more information about table display options, see
Table Columns and Column Heading Features, page 3-26.
SHDSL Controller Dialog Box
Use the SHDSL Controller dialog box to configure SHDSL controllers.
Navigation Path
Go to the SHDSL Policy Page, page K-47, then click the Add or Edit button
beneath the table.
Related Topics
• Defining SHDSL Controllers, page 15-44
• PVC Policy Page, page K-54
• Discovering Policies on Devices Already in Security Manager, page 7-10
Field Reference
Delete button Deletes the selected DSL controller definition from the table.
Save button Saves your changes to the Security Manager server but keeps them private.
Note To publish your changes, click the Submit button on the toolbar.
Table K-21 SHDSL Page (Continued)
Table K-22 SHDSL Dialog Box
Element Description
Name The name of the controller. Enter a name manually, or click Select to display
a dialog box for generating a name. See Controller Auto Name Generator
Dialog Box, page K-53.
Description Additional information about the controller (up to 80 characters).
