Appendix K Router Platform User Interface Reference
SHDSL Policy Page
K-48
User Guide for Cisco Security Manager 3.2
OL-16066-01
• (Policy view) Select Router Interfaces > Settings > DSL > SHDSL from the
Policy Type selector. Right-click SHDSL to create a policy, or select an
existing policy from the Shared Policy selector.
Related Topics
• PVC Policy Page, page K-54
• ADSL Policy Page, page K-42
• SHDSL on Cisco IOS Routers, page 15-43
• Chapter K, “Router Platform User Interface Reference”
Field Reference
Table K-21 SHDSL Page
Element Description
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
Name The name of the DSL controller.
Description An optional description of the controller.
Shutdown Indicates whether the DSL controller is in shutdown mode.
Configure ATM Mode Indicates whether the DSL controller has been set into ATM mode.
Line Termination The line termination set for the router (CPE or CO).
DSL Mode The operating mode defined for the DSL controller.
Line Mode The line mode defined for the DSL controller.
Line Rate The line rate (in kbps) defined for the DSL controller.
Note A value is displayed in this column only if the line mode is not set to
Auto.
SNR Margin Current The current signal-to-noise ratio on the controller.
SNR Margin Snext The self near-end crosstalk (Snext) signal-to-noise ratio on the controller.
Add button Opens the SHDSL Controller Dialog Box, page K-49. From here you can
define the settings for a DSL controller.
Edit button Opens the SHDSL Controller Dialog Box, page K-49. From here you can
edit the selected DSL controller definition.
