K-43
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
ADSL Policy Page
Related Topics
• PVC Policy Page, page K-54
• SHDSL Policy Page, page K-47
• ADSL on Cisco IOS Routers, page 15-38
• Chapter K, “Router Platform User Interface Reference”
Field Reference
Table K-19 ADSL Page
Element Description
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
ATM Interface The ATM interface on which ADSL settings are defined.
Interface Card The type of device or ADSL interface card on which the ATM interface
resides.
Bandwidth Change Indicates whether the router makes dynamic adjustments to VC bandwidth
as overall bandwidth changes. (This is relevant only when IMA groups are
configured on the ATM interface.)
DSL Operating Mode The DSL operating mode for this interface.
Tone Low Indicates whether the interface is using the low tone set (carrier tones 29
through 48).
Add button Opens the ADSL Settings Dialog Box, page K-44. From here you can define
the ADSL settings for a selected ATM interface.
Edit button Opens the ADSL Settings Dialog Box, page K-44. From here you can edit
the selected ADSL definition.
Delete button Deletes the selected ADSL definition from the table.
Save button Saves your changes to the Security Manager server but keeps them private.
Note To publish your changes, click the Submit button on the toolbar.
