Appendix K Router Platform User Interface Reference
NAT Policy Page
K-4
User Guide for Cisco Security Manager 3.2
OL-16066-01
Navigation Path
Go to the NAT Policy Page, page K-3, then click the Interface Specification tab.
Related Topics
• NAT Page—Static Rules Tab, page K-6
• NAT Page—Dynamic Rules Tab, page K-12
• NAT Page—Timeouts Tab, page K-15
Field Reference
Edit Interfaces Dialog Box—NAT Inside Interfaces
When you configure a translation rules policy on a Cisco IOS router, use the Edit
Interfaces dialog box to specify which interfaces will act as the inside interfaces
for address translation. Inside interfaces typically connect to a LAN that the router
serves.
Navigation Path
Go to the NAT Page—Interface Specification Tab, page K-3, then click the Edit
button in the NAT Inside Interfaces field.
Related Topics
• Designating Inside and Outside Interfaces, page 15-6
• Edit Interfaces Dialog Box—NAT Outside Interfaces, page K-5
Table K-1 NAT Interface Specification Tab
Element Description
NAT Inside Interfaces The interfaces that act as the inside interfaces for address translation. Click
Edit to display the Edit Interfaces Dialog Box—NAT Inside Interfaces,
page K-4. From here you can define these interfaces.
NAT Outside Interfaces The interfaces that act as the outside interfaces for address translation. Click
Edit to display the Edit Interfaces Dialog Box—NAT Outside Interfaces,
page K-5. From here you can define these interfaces.
Save button Saves your changes to the Security Manager server but keeps them private.
Note To publish your changes, click the Submit button on the toolbar.
