Network Router User Manual
Table Of Contents
- Router Platform User Interface Reference
- NAT Policy Page
- Router Interfaces Page
- Advanced Interface Settings Page
- AIM-IPS Interface Settings Page
- Dialer Policy Page
- ADSL Policy Page
- SHDSL Policy Page
- PVC Policy Page
- PPP/MLP Policy Page
- AAA Policy Page
- Accounts and Credential s Policy Page
- Bridging Policy Page
- Clock Policy Page
- CPU Policy Page
- HTTP Policy Page
- Console Policy Page
- VTY Policy Page
- Secure Shell Policy Page
- SNMP Policy Page
- DNS Policy Page
- Hostname Policy Page
- Memory Policy Page
- Secure Device Provisioning Policy Page
- DHCP Policy Page
- NTP Policy Page
- 802.1x Policy Page
- Network Admission Control Policy Page
- Logging Setup Policy Page
- Syslog Servers Policy Page
- Quality of Service Policy Page
- BGP Routing Policy Page
- EIGRP Routing Policy Page
- OSPF Interface Policy Page
- OSPF Process Policy Page
- RIP Routing Policy Page
- Static Routing Policy Page
K-37
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
Dialer Policy Page
• (Policy view) Select Router Interfaces > Settings > Dialer from the Policy
Type selector. Right-click Dialer to create a policy, or select an existing
policy from the Shared Policy selector.
Related Topics
• Configuring Dial Backup, page 10-37
• Chapter K, “Router Platform User Interface Reference”
Field Reference
Table K-16 Dialer Page
Element Description
Dialer Profiles table
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
Interface The interface role that the dialer interface uses.
Profile Name The name of the dialer profile.
Dial Pool The dialing pool that this dialer profile uses.
Dial Group The dialer group that this dialer profile uses.
Interesting Traffic ACL The ACL that defines which traffic can use this dialer profile.
Dial String The phone number that the dialer calls.
Idle Timeout The defined interval after which an uncontested idle line is disconnected.
Fast Idle The defined interval after which a contested idle line is disconnected.
Add button Opens the Dialer Profile Dialog Box, page K-38. From here you can define
a dialer profile.
Edit button Opens the Dialer Profile Dialog Box, page K-38. From here you can edit the
selected dialer profile.
Delete button Deletes the selected dialer profiles from the table.
Dialer Physical Interfaces (BRI) table
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
Interface The name of the interface role that the physical interface uses.
