Field Reference
Table K-124 RIP Redistribution Mapping Dialog Box
Element Description
Protocol to Redistribute The routing protocol that is being redistributed:
• Static—Redistributes static routes. You can define a single mapping for
each route.
• EIGRP—Redistributes an EIGRP autonomous system. Enter the AS
number in the displayed field. You can define a single mapping for each
AS.
• BGP—Redistributes a BGP autonomous system. You can define a single
BGP mapping on each device. If you configured a BGP AS in the BGP
Setup tab, the AS number is displayed. Otherwise, a message is
displayed indicating that no BGP AS was defined. See BGP
Page—Redistribution Tab, page K-223.
Protocol to Redistribute
(continued)
• OSPF—Redistributes a different OSPF process. You can define a single
mapping for each process. Select a process from the displayed list, then
select one or more match criteria:
– Internal—Routes that are internal to a specific AS.
– External1—Routes that are external to the AS and imported into
OSPF as a Type 1 external route.
– External2—Routes that are external to the AS and imported into the
selected process as a Type 2 external route.
– NSAAExternal1—Not-So-Stubby Area (NSSA) routes that are
external to the AS and imported into the selected process as Type 1
external routes.
– NSAAExternal2—(NSSA) routes that are external to the AS and
imported into the selected process as Type 2 external routes.
• Connected—Redistributes routes that are established automatically by
virtue of having enabled IP on an interface. These routes are
redistributed as external to the AS.
Default Metric Establishes a default value for the redistributed route. Valid values range
from 0 to 16.
