Appendix K Router Platform User Interface Reference
RIP Routing Policy Page
K-258
User Guide for Cisco Security Manager 3.2
OL-16066-01
Navigation Path
Go to the RIP Routing Policy Page, page K-255, then click the Authentication
tab.
Related Topics
• Defining RIP Interface Authentication Settings, page 15-211
• RIP Page—Setup Tab, page K-255
• RIP Page—Redistribution Tab, page K-260
• RIP Routing Policy Page, page K-255
Field Reference
Tip To choose which columns to display in the table, right-click a column header, then
select Show Columns. For more information about table display options, see
Table Columns and Column Heading Features, page 3-26.
Table K-121 RIP Authentication Tab
Element Description
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
Interfaces The name of an interface (as defined by an interface role) on which RIP is
enabled.
Authentication The type of RIP neighbor authentication that is enabled for the selected
interface role—clear text or MD5.
Key ID The identification number of the authentication key used for MD5
authentication.
Add button Opens the RIP Authentication Dialog Box, page K-259. From here you can
define authentication for an additional RIP interface.
Edit button Opens the RIP Authentication Dialog Box, page K-259. From here you can
edit the authentication properties of the selected RIP interface.
Delete button Deletes the selected authentication definitions from the table.
