K-257
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
RIP Routing Policy Page
Edit Interfaces Dialog Box—RIP Passive Interfaces
When you configure a RIP routing policy on a Cisco IOS router, use the Edit
Interfaces dialog box to specify which interfaces will not send updates to their
routing neighbors.
Navigation Path
Go to the RIP Page—Setup Tab, page K-255, then click the Edit button in the
Passive Interfaces field.
Related Topics
• Defining RIP Setup Parameters, page 15-210
Field Reference
RIP Page—Authentication Tab
Use the RIP Authentication tab to view, create, edit, and delete the neighbor
authentication settings of RIP interfaces.
Table K-120 Edit Interfaces Dialog Box—RIP Passive Interfaces
Element Description
Interfaces The interfaces that do not send updates to their routing neighbors. You can
enter interfaces, interface roles, or both.
For more information, see Specifying Interfaces During Policy Definition,
page 9-135.
Select button Opens an Object Selectors, page F-593 for selecting interfaces and interface
roles. Using the selector eliminates the need to manually enter this
information.
If the interface role you want is not listed, click the Create button in the
selector to display the Interface Role Dialog Box, page F-464. From here
you can define an interface role object.
OK button Saves your changes and closes the dialog box. Your selections are displayed
in the Passive Interfaces field of the RIP Setup tab.
