Appendix K Router Platform User Interface Reference
RIP Routing Policy Page
K-256
User Guide for Cisco Security Manager 3.2
OL-16066-01
Related Topics
• Defining RIP Setup Parameters, page 15-210
• RIP Page—Authentication Tab, page K-257
• RIP Page—Redistribution Tab, page K-260
• Supported IP Address Formats, page 9-145
• Understanding Network/Host Objects, page 9-144
Field Reference
Table K-119 RIP Setup Tab
Element Description
Networks The directly connected networks associated with the RIP route. Enter one or
more network addresses or network/host objects, or click Select to display
an Object Selectors, page F-593.
If the network you want is not listed, click the Create button in the selector
to display the Network/Host Dialog Box, page F-477. From here, you can
define a network/host object.
Passive Interfaces The interfaces that do not send updates to their routing neighbors. Click Edit
to display the Edit Interfaces Dialog Box—RIP Passive Interfaces,
page K-257. From here you can define these interfaces.
Auto-Summary When selected, enables the automatic summarization of subnet routes into
network-level routes. Summarization reduces the size of routing tables,
thereby reducing the complexity of the network. This feature is enabled by
default.
When deselected, automatic summarization is disabled.
Note Disable automatic summarization when performing routing between
disconnected subnets. When this feature is disabled, subnets are
advertised.
Save button Saves your changes to the Security Manager server but keeps them private.
Note To publish your changes, click the Submit button on the toolbar.
