Appendix K Router Platform User Interface Reference
OSPF Process Policy Page
K-248
User Guide for Cisco Security Manager 3.2
OL-16066-01
Tip To choose which columns to display in the table, right-click a column header, then
select Show Columns. For more information about table display options, see
Table Columns and Column Heading Features, page 3-26.
OSPF Area Dialog Box
Use the OSPF Area dialog box to add or edit the properties of an OSPF area. You
should define at least one area for each OSPF process (see OSPF Setup Dialog
Box, page K-245), but deployment will not fail if you do not.
Navigation Path
Go to the OSPF Process Page—Area Tab, page K-247, then click the Add or Edit
button beneath the table.
Related Topics
• Defining OSPF Area Settings, page 15-194
• Supported IP Address Formats, page 9-145
• Understanding Network/Host Objects, page 9-144
Field Reference
Table K-115 OSPF Area Dialog Box
Element Description
Process ID The process ID associated with the OSPF area. The list contains the OSPF
processes defined in the OSPF Process Page—Setup Tab, page K-243.
Area ID The area ID number associated with the selected process. Valid values range
from 0 to 4294967295.
Networks The networks to add to the OSPF area. Enter one or more network addresses
or network/host objects, or click Select to display an Object Selectors,
page F-593.
If the network you want is not listed, click the Create button in the selector
to display the Network/Host Dialog Box, page F-477. From here you can
define a network/host object.
